High Voltage Oil Purifier Transformer Oil Filter With Favorable Price

Introduction:

3000l/h Insulating Oil Treatment Machine Transformer Oil Purifier is a creative design introducing domestic and international advanced technology.Dehydration,degasfication and filtration of insulation oil especially aging transformer oil.Roots pump is combined with vacuum pump to generate powerful working efficiency and remove water,gas more thoroughly and rapidly.

Contamination can be removed returning the insulating oil to it's original specifications. The system incorporates high vacuum to dehydration, degasification and filter contaminated oil. Remove impurities and restores / improves the chemical and physical properties of oils. During the process,the machine can remove gas, particulate, and significant amounts of free water contamination.

Contaminants in transformer oil:
  1.Solid particles like rust scales, dust and fibres
  2.Generation of carbon particles due to ageing of switchgear
  3.Oil absorbs moisture resulting in free and dissolved water

  4.Absorption of air
  5.Aging fluids produce absorbed gases, causing equipment failure and arc suppression in switchgear
  6.Sludge formation
  7.Increase in acidity level
  8.Chemical products are caused by oxidation, as well as cross contamination of other products.

Through the vacuum dehydrator, degasification, filtration processes, the dissolved gases and moisture, solid particulate, free carbon,acid contamination can be completely removed,thus improve the oil dielectric strength,oil color,and oil quality as well.

Index Guarantee after Filtering

Chongqing TOP is a professional leading manufacturer and supplier of oil purifiers and various related testers. We consists of departments respectively for technological development, machinery manufacture, instrument manufacture, quality control etc. On basis of mature development and manufacture technology and highly qualified production management team, the products own high quality, easy operation, excellent performance and lone service life.

Customer satisfaction is our utmost priority thus, customer service team is always on the brink to help our customers with their queries at any time.

We believe in working as a unit with an attitude of complete trust and understanding and are determined to provide safe, reliable and competitively priced products to our customers.

TOP Oil Purifiers uses single or multi-stage filtration to remove, particulate, free water, and small quantities of dissolved water if necessary. The systems are usually customized to suite the specific customer application. Oil "regeneration", "reclamation", "recycling" are all terms used to describe the process of restoring used, aged, contaminated oils to "like new" reusable condition. The reclamation process removes free water, most dissolved water, dissolved gas, particulate, carbon contamination, acids, oxidation by products, most color bodies, wear metals, and most additive chemicals.

TOP Oil Testers works on the development, production, market, technical and after-sale service for petrochemical analyzers, transformer substation electrical testing equipment and circuit detecting equipment. Main products are water content testers, surface/interfacial tension testers, flash point testers, kinematic viscosity testers, oil acidity testers, insulation oil dielectric strength testers, transformer characteristics testers, relay protection testers, high voltage testing equipment etc.

Honest Team - TOP always honestly treat you and keep faith to make you satisfied with every cooperation with us.
Sincere Communication - TOP sincerely communicate with you to guarantee the provided products to be your ideal ones.
Reliable Quality -TOP own high quality and performance for every TOP product is under strict quality control and testing.
Service Commitment - TOP bring you prompt, considerate and professional aftersale service and technical support, and explore technology future together.

CE CCPIT ISO Certificates

machining

cutting

welding and polishing

assembly semi-finished machine

finished machine

packed machine with enclosure

for more details,we are here sincerely waiting for your inquiry.
