Help CenterSHENZHEN Factory High Precision HD Digital Camera Video Measuring Instrument
Related Products
-
High Quality Professional Coordinate Measuring Machine Measurement Equipment For Precision Parts With High AccuracyNegotiableMOQ: 1 -
2021 Professional Hot Selling High Precision Vision Measurement Machine 2DNegotiableMOQ: 1
-
High Quality Directory Supplier Vision Measuring Machine With High Accuracy For Dimension MetrologyNegotiableMOQ: 1
-
High Tech 2.5d Dimensions Measuring Machine With High PrecisionNegotiableMOQ: 1
-
Factory Direct Supply Professional Measuring Machine Vision System For Dimension MeasurementNegotiableMOQ: 1
| Paramter and Model | AQC210 | AQC320 | AQC430 | AQC540 | |
| Workbench | Platfom size(mm) | 360*260 | 460*360 | 560*460 | 720*620 |
| Glass table size(mm) | 250*150 | 350*250 | 450*350 | 550*450 | |
| Bearing(kg) | 20 | 20 | 20 | 20 | |
| Travel | X axis(mm) | 200 | 300 | 400 | 500 |
| Y axis(mm) | 100 | 200 | 300 | 400 | |
| Z axis(mm) | 200 | 200 | 200 | 200 | |
| Image and measurement system | Display resolution(μm) | 1/0.5(Optional) | |||
| Instrument precision(μm) | (3+L/200)μm | ||||
| Imaging system(CCD) | HD Digital Camera | ||||
| Zoom objective(X) | High Precision Zoom Objective 0.7~4.5X | ||||
| Total video magnification(x) | 30~200X | ||||
| Working distance(mm) | 96mm | ||||
| Light source | LED programmable partiton light source(Coaxial light source optional) | ||||
| Outline dimension(mm) | 610*550*970 | 740*660*970 | 880*760*970 | 1090*720*1700 | |
|
Weight(kg) |
250kg | 360kg | 450kg | 700kg | |
| Power supply | 220V AC 50Hz | ||||
1.Element measurements: multi-point measurement point, line, circle, arc, angle, ellipse, rectangle measuring points provided, automatic identification of point, line, circle, arc.
2.element structure: the center structure, the intersection of structure, the mid-point structure, line structure, a round structure, the angle structures.
3.preset elements: point, line, circle, arc.
4.graphics: coordinate translation, straighten the work piece.
5.arbitrary axis straightened, coordinate system reset.
6.graphic to enlarge, reduce graphics, graphics translation, graphic printing graphic is selected, uncheck, graphics removed.
7.Set the zoom, graphics narrow, graphic print radio is selected, deselect, graphics removed.
8 .Set the gray scale image, saturation, contrast, image saved as a BMP format.
9.a variety of edge detection mode, the computer automatically get points, automatic identification circle, arc greatly enhance the speed of mining points.
Located at Shenzhen city, Baoan District Guangdong Province.High-tech enterprise integrating R & D and production.
Mainly engaged in video measuring system,have been professional in the industry of video measuring system for 15 years.
Our main products are :Manual Image Measuring Instrument, CNC Video Measuring System,Gantry Large Stroke Vision Measurement Machine, One Key Rapid Video Measuring Machine, CMM Coordinate Measuring Machine, Profile Projector ,Laser Marking Machine etc .
Products widely applied in industrial applications such as machines,
electronics, molds, plastics, metals, die-cutting, electrical appliances, mobile,
phone, home appliance, computer, LCD TV, printed circuit board (PCB), automotive, aviation etc.
AUSKY always carries on the scientific manage system ,strong adhere to the policy :Quality Firstly,Customer Firstly and Credit Firstly .
We also have a perfect after sale service system ,These can ensure that we provide customers with the best products and services.
