Commercial Food Lyophilizers for Fruit and Vetables

Commercial Food Lyophilizers for Fruit and Vetables photo-1
Commercial Food Lyophilizers for Fruit and Vetables photo-2
Commercial Food Lyophilizers for Fruit and Vetables photo-3
US$ 40000 - 90000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Nixtar
Place of Origin:
China
Model Number:
FD100
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
15 days
Brand Name Nixtar
Place of Origin China
Model Number FD100
Type Dryer
Certification CE
After-sales Service Provided Engineers available to service machinery overseas
Warranty 12 Months
Weight 5.5T
Dimension(L*W*H) 5500*1700*2500mm
Condition New
Voltage 380V/50Hz/3P
Power(W) 25Kwh

NiXTAR FD series food freeze dryers and lyophilizers are commercial units mainly use for food freeze drying. Rapid drying cycle and industrial high capacity. When we design the machines, we care your long-term benefit, designed to deliver and to last, guarantee your high quality freeze drying at lowest cost.

There are 2 kinds of machine structure: FD50~FD300 are medium capacity freeze dryers mainly for commercial areas, the machine come with integrated structure, plug and play deliver; FD300~FD2000 are large freeze drying plant mainly for industry mass production, deliver by pieces, need Nixtar engineers install and debug.

We deeply know that freeze dry systems cannot be compromised. Your lyophilization plant have to be solid and energy saving to reduce your freeze drying cost. In another hand is increase your competitiveness in market. NiXTAR uses its knowledge in the field and help your business health growth, our cutting-edge technologies guarantee your food freeze drying solution is economic, energy saving, labor saving and time saving.

Models and Technical Parameters:


ModelFD50FD100FD200FD300
Trays Area4.8m29.7m219m230.6m2
No. of Shelves9+19+112+113+1
Shelf Size620*910mm920*1220mm1230*1320mm1310*1850mm
Condenser50kgs/24hrs100kgs/24hrs200kgs/24hrs300kgs/24hrs
Power Install15kwh21.5kwh40kwh65kwh
Install SizeW/1300
L/2800
H/2100mm
W/1500
L/4000
H/2300mm
W/1700
L/5000
H/2500mm
W/2300
L/6500
H/2800mm

1,   FD50 to FD300 Commercial freeze drying machine. Drying chamber can be Rectangular or Cylindrical, Shelves and Trays can be Stainless Steel or Aluminum Alloy.

2,   FD300 to FD2000 Industrial freeze drying machine. Drying chamber is cylindrical, Shelves and Trays are Aluminum Alloy.


ModelFD300FD500FD1000FD2000
Trays Area29.9m250.8m2101m2206m2
No. of Shelves8+117+117+117+1
Shelf Modules2224
Shelf Size570*3550mm570*2850mm570*5610mm630*5100mm
Condenser300kgs/24hrs500kgs/24hrs1000kgs/24hrs2000kgs/24hrs
Power Install70kwh120kwh220kwh400kwh
Drying ChamberW/2500
L/4000
H/3500mm
W/3100
L/7000
H/3500mm
W/3100
L/11000
H/3500mm
W/3100
L/18000
H/3500mm


Product Tags: lyophilizer , food lyophilizer , commercial lyophilizer
