Product introduction ※
Bochuang spacetime bcsk-808m2 mobile phone signal shield is a high-tech product carefully developed by our factory using foreign advanced technology, aiming at the continuous development of communication system and according to the actual situation of foreign mobile communication. It can cut off GSM / CDMA / AMPS / DCS / PHS / 3G (WCDMA, TD-SCDMA and CDMA2000) within a radius of 1-25m (about 10-250m2, and the shielding range can be adjusted according to the required place) And 4G mobile phone signal, 2.4G wireless signal, so that the mobile phone can not send and answer, and can not send or receive short messages, but will not interfere with the work of other electronic devices, so as to ensure the safety of the required place. When the mobile phone leaves the partition range, it can resume normal use without any damage to people.
※ product features ※
1. Effectively shield all communication signals such as CDMA (China Telecom), GSM (China Mobile, China Unicom), SCDMA (Netcom, PHS), DCS (1800MHz), PCS (1900MHz), PHS (Telecom PHS), 3G mobile phone signals and 4G mobile phone signals,
2. Ultra thin shell, the surface can be labeled or silk screen printed according to customers' needs (silk screen printing service is provided free of charge)
3. Transmission Power 12W
4, effective shielding distance 1-25 meters adjustable (before commissioning)
※ applicable place ※
All places
※ after sales service ※
Guaranteed repair within one year
※ performance index ※
Serial number technical standard technical parameter
one CDMA band transmission frequency 869-894MHz
two DCS / PHS frequency band transmission frequency 1800-1920MHz
three GSM band transmission frequency 925-965MHz
four TD-SCDMA band transmission frequency 2005-2035MHz
five WCDMA / CDMA2000 band transmission frequency 2110-2175MHz
six 2.4G band transmission frequency 2400-2500MHz
seven 4G1 band transmission frequency 2300-2390MHz
eight 4G2 band transmission frequency 2550-2660MHz
nine Power Supply Power input ac160v-240v output DC 5V 15A
ten size 350(L) × 110(W) × 37(H)
eleven weight About 2000 g
twelve Isolation range 1-25m (about 10-250m2, the shielding range can be adjusted according to the required place)
thirteen Actionable type All mobile phones (2G + 3G + 4G) 2.4G wireless signals, etc
fourteen Use ring
Environmental conditions temperature - 10 to –55℃
relative humidity ≤90%(RH)
atmospheric pressure 86-106kPa
position Indoor and outdoor
※ installation instructions ※
This product can be directly fixed on the wall or ceiling with screws. The surface temperature of this product can reach 50 ℃, so please stay away from low heat resistant objects.
Installation height: 1.0-2.0m, the best effect
Installation direction: do not point the antenna of the mobile phone signal shield towards the mobile phone base station, otherwise the use effect will be affected.
1) . antenna connection
The antenna adopts error proof design and can be inserted and installed only when it is correct. (Note: If you turn on the power switch without installing the antenna, the unit may be damaged)
2) . power connection
Check the power switch of the host, confirm that the power switch is in the off position, insert the output plug of the power transformer into the power socket in the middle of the left side of the host, and connect the input plug of the power transformer with the AC220V power supply.
| Function details | Function description |
| External antenna | External high gain antenna； |
| External power supply | The external power line is connected, the external power supply is 24V, and the machine works continuously for 24h; |
| External switch | Main power switch of equipment; |
