Products Features
Features:This model has an ergonomic design and is manufactured using numerically-controlled machine tools;
A specimen retraction function protects the specimen from blade damage;
A trim button allows for easy switching between trim and sectioningmode;
Includes a counting function for the number of sections and the total thickness;
The cryogenic refrigeration system utilizes a forced cooling structure.
The refrigeration chamber, freezing shelf, blade holder, and specimen holder are cooled independently by a German double compressor to enhance cooling performanceandincreasecoolingspeed.
ImportedR404Anon-CFC refrigerantsthatareenvironment-friendly;
Achieves the desirable sectioning temperature within 20 minutes after turning on the unit whenusingthefast coolingmode;
UV option enables surface disinfection of harmful bacteria, viruses, and spores by using 35minaftereachuse;
It alsohaslow-voltage DCshadowlesslamp;
Semiconductorcoolingfunctioncanbeturnedonandoff;
Hearableandremovable glass door;
Twodefrostingmodes:time defrostingandmanualdefrosting;
Microtome is outside of the refrigeration chamber to avoid the effect of heat-expansion andcoldcontraction,thusminimizingtheneedformaintenance; User-friendlyintelligent
operationalinterfaceis easytolearnandoperate;
LCD screen displays the number of sections and the total thickness, section thickness, specimen retraction value, temperature setting, date, time, temperature and on/off timer areall includedonthemaindisplay;
Auto sleep function results in longer compressor life: the cryo-chamber temperature automatically stays in a range of -1 to -9℃ under the sleep mode, and returns to the sectioningtemperaturewithin 15minutesaftercancelingthesleepmode;
Keyboardlockingfunctiontoavoidaccidentmisoperation;
Amechanicalhand-wheellockensuresafechamberaccess,16positionforlocking;
The red bar on the blade holder covers the whole length of blade to protect the user and thepushbarenableseasychangingoftheblade;
A large-size quick-freezing shelf allows for the preparation of 17 specimens at the same time;
Twoholesfor semiconductorrefrigeration; Ithascleaningdevice,easyhelpcustomertocleantheunit;
Specimen Orientation: XY – 8°; Z– 360° adjustable at any orientations to ensure precise placement;
Self-detection function for the temperature senor, can help to warn the failure on temperaturesenor.
Product Description
ChamberTemperature:from-10℃ ~-40℃
SpecimenHeadTemperature:-10℃ ~-40℃
Timetoreach-40℃ ofthequick-freeze shelf:60minutes
LowestpossibletemperatureofthePeltierelement: -45℃
Lowest possible temperature of the Peltier element together with quick-freeze shelf: below-60℃ RunningtimeofthePeltierelement:15minutes
MaximumSpecimenSize:35mm×35mm
SpecimenVerticalStroke: 60mm
SpecimenHorizontalStroke:20mm
ElectricCoarseFeed:rapid0.7mm/s; slow0.35mm/s
Thesectionthickness isadjustedinarangeof1μmto100μm 1μm-20μm increments1μm; 20μm-40μm increments2μm; 40μm-100μm increments5μm;
TrimSectionThicknessFeed:adjustedintherangeof10μmto400μm 10μm-50μm increments5μm; 50μm-100μm increments10μm; 100μm-400μm increments 50μm;
SpecimenRetractionDistance:adjustableinarange of0~80μm,in5μmincrements WorkingVoltage:AC220V±10%50Hz(standardmodel);AC110V±10%60Hz
Power: 600W
Dimensions:650×800×1160mm (W×D×H)
NetWeight: 115kg
