Portable 10 Inch 12 Channel 12 Lead Electrocardiograp ECG Machine for Hospital
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
2000
Annual Export Value:
US$2.5 Million - US$5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Manufacturer 5.7 Color Screen 6 Channel ECG Machine for Children AdultNegotiableMOQ: 1 -
Portable 3 Channel ECG Machine 7 Inch Display Electrocardiography for HospitalNegotiableMOQ: 1
-
10.4 Inch LED Portable B&W Ultrasound Scanner Full Digital Portable Ultrasound MachineNegotiableMOQ: 1
-
12.1 Inch LED Display Portable Ultrasound Scanner Black and White Ultrasound MachineNegotiableMOQ: 1
-
Professional 15 Inch LED Full Digital Color Doppler System for HospitalNegotiableMOQ: 1
Product Description
Specification
Features |
10 inch screen touch screen Support Ecg analysis capabilities |
||||
Lead |
standard 12 leads |
||||
lead acquisition |
synchronously 12 leads |
||||
Input circuit |
Floating; Protection circuit against Defibrillator effect |
||||
Input Impedance |
≥50MΩ |
||||
Input circuit current |
≤0.0.05μA |
||||
Record mode |
Automatic: 3CH×4+1R, 3CH×4, 3CHx2+2CHx3,3CHx2+2CHx3+1R,6CHX2; Manual: 3CH, 2CH, 3CH+1R, 2CH+1R; Rhythm: Any lead selectable. |
||||
Filter |
EMG Filter: 25 Hz / 30 Hz / 40Hz/75 Hz / 100 Hz / 150Hz DFT Filter: 0.05 Hz/ 0.15 Hz AC Filter: 50 Hz / 60Hz |
||||
CMRR |
>100dB |
||||
Patient current leakage |
<10μA |
||||
Input Circuit Current |
<0.05µA |
||||
Frequency Response |
0.05Hz~150Hz (-3dB) |
||||
Sensitivity |
2.5mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV |
||||
Anti-baseline Drift |
Automatic |
||||
Time constant |
≥3.2s |
||||
Noise level |
<15μVp-p |
||||
Paper speed |
12.5 mm/s, 25 mm/s, 50 mm/s |
||||
Recording mode |
Thermal printing system |
||||
Paper specification |
Sun-7031:80mmx20m paper rollSun-7062:120mmx20m paper roll |
||||
LCD display |
7" graphic LCD |
||||
Safety classification |
IEC60601-1 class I, type CF |
||||
Power supply |
AC: 100~240V, 50/60Hz, 30VA~100VA |
||||
Fuse |
AC220V±10% 2*Φ5×20mm,T2A/250V AC time lag |
||||
