YRTM325 Rotary Table Bearing , High Precision Bearing Cylindrical Bearing

YRTM325 Rotary Table Bearing , High Precision Bearing Cylindrical Bearing thumbnail-1
YRTM325 Rotary Table Bearing , High Precision Bearing Cylindrical Bearing thumbnail-2
YRTM325 Rotary Table Bearing , High Precision Bearing Cylindrical Bearing thumbnail-3
YRTM325 Rotary Table Bearing , High Precision Bearing Cylindrical Bearing thumbnail-4
YRTM325 Rotary Table Bearing , High Precision Bearing Cylindrical Bearing thumbnail-5
YRTM325 Rotary Table Bearing , High Precision Bearing Cylindrical Bearing photo-1
YRTM325 Rotary Table Bearing , High Precision Bearing Cylindrical Bearing photo-2
YRTM325 Rotary Table Bearing , High Precision Bearing Cylindrical Bearing photo-3
YRTM325 Rotary Table Bearing , High Precision Bearing Cylindrical Bearing photo-4
YRTM325 Rotary Table Bearing , High Precision Bearing Cylindrical Bearing photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
2000
Annual Export Value:
US$5 Million - US$10 Million
Contact Supplier Request Quote Chat Now
Crossed Roller Bearings
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Description


Axial radial bearings YRT product description


BYC Axial radial bearings YRT are axial and radial combined cylindrical roller bearings, including two thrust needle roller bearings and a radial cylindrical roller bearing with the combination of axial and radial preload, For the convenience of transportation and fixing, two or three symmetrical screws are fastened to the two rings in order to prevent rollers and rings generating collisions which influence bearing accuracy.
Products Show
Product Paramenters

Model
 Number
Boundary Dimensions

Weight
d
D
H
unit： mm
Kg
YRTS200
200
300
30
9.7
YRTS260
260
385
36.5
18.3
YRTS325
325
450
40
25
YRTS395
395
525
42.5
33
YRTS460
460
600
46
45

Model
Number
Boundary Dimensions

Weight
d
D
H
unit： mm


Kg
YRTM150
150
240
40
6.2
YRTM180
180
280
43
7.7
YRTM200
200
300
45
9.7
YRTM260
260
385
55
18.3
YRTM325
325
450
60
25
YRTM395
395
525
65
33
YRTM460
460
600
70
45
Related products
Manufacturing Technique
Application Field
Product packaging

Plan01

Blister packaging

Plan02

Carton packaging

Plan03

Wooden case packing


Packaging & Shipping.


1. Industrial Neutral Packing,Package as your requirements.
2. Small size Bearings:Plastic vacuum packaging bag+Paper Box/Neutral Carton.
3.Large size Bearings:Plastic film+Brown paper+Roll tape+Wooden Box.
4.Shipping:By air or By sea:DHL/TNT/UPS/EMS etc.
Company Profile
Company Information
Luoyang BoYing Bearing Co., Ltd, (BYC) is a professional manufacturer of high precision bearings,The main products are Crossed roller bearings , YRT Rotary Table Bearings , Crossed Tapered Roller Bearings , Cylindrical Thrust Roller Bearing , Angular Contact Ball Bearings , Thin Section Bearings, Slewing Bearings , Ball Screw Bearings . The accuracy grades are P5, P4, P2, and the size of inner ring are ranging from Φ50mm --- Φ1300mm. Our products are optimal for Robotics, Machine Tools, Rotary Table,medical equipment, measuring instruments ,mainly to replace the imported bearings. Also, we can design , choose and manufacture non-standard precision bearings as customer requested.
