Products Description


Axial radial bearings YRT product description


BYC Axial radial bearings YRT are axial and radial combined cylindrical roller bearings, including two thrust needle roller bearings and a radial cylindrical roller bearing with the combination of axial and radial preload, For the convenience of transportation and fixing, two or three symmetrical screws are fastened to the two rings in order to prevent rollers and rings generating collisions which influence bearing accuracy.
Products Show
Product Paramenters


Model
Number
Boundary
 Dimensions

Limiting

Weight

d
D
H
Speed(grease)

unit： mm
r/min
Kg
YRT50
50
126
30
440
1.6
YRT80
80
146
35
530
2.4
YRT100
100
185
38
430
4
YRT120
120
210
40
340
5.3
YRT150
150
240
40
320
6.2
YRT180
180
280
43
280
7.7
YRT200
200
300
45
260
9.7
YRT260
260
385
55
200
18.3
YRT325
325
450
60
170
25
YRT395
395
525
65
140
33
YRT460
460
600
70
120
45
YRT580
580
750
90
80
89
YRT650
650
870
122
65
170
YRT850
850
1095
124
50
253
YRT950
950
1200
132
40
312
YRT1030
1030
1300
145
39
375
YRT1200
1200
1490
164
25
450
Related products
Manufacturing Technique
Application Field
Product packaging

Plan01

Blister packaging

Plan02

Carton packaging

Plan03

Wooden case packing


Packaging & Shipping.


1. Industrial Neutral Packing,Package as your requirements.
2. Small size Bearings:Plastic vacuum packaging bag+Paper Box/Neutral Carton.
3.Large size Bearings:Plastic film+Brown paper+Roll tape+Wooden Box.
4.Shipping:By air or By sea:DHL/TNT/UPS/EMS etc.
Company Profile
Company Information
Luoyang BoYing Bearing Co., Ltd, (BYC) is a professional manufacturer of high precision bearings,The main products are Crossed roller bearings , YRT Rotary Table Bearings , Crossed Tapered Roller Bearings , Cylindrical Thrust Roller Bearing , Angular Contact Ball Bearings , Thin Section Bearings, Slewing Bearings , Ball Screw Bearings . The accuracy grades are P5, P4, P2, and the size of inner ring are ranging from Φ50mm --- Φ1300mm. Our products are optimal for Robotics, Machine Tools, Rotary Table,medical equipment, measuring instruments ,mainly to replace the imported bearings. Also, we can design , choose and manufacture non-standard precision bearings as customer requested.
