Latest Technology for Palm Fruit Thresher in Modern Plant Palm Oil Plant

Latest Technology for Palm Fruit Thresher in Modern Plant Palm Oil Plant thumbnail-1
Latest Technology for Palm Fruit Thresher in Modern Plant Palm Oil Plant thumbnail-2
Latest Technology for Palm Fruit Thresher in Modern Plant Palm Oil Plant thumbnail-3
Latest Technology for Palm Fruit Thresher in Modern Plant Palm Oil Plant photo-1
Latest Technology for Palm Fruit Thresher in Modern Plant Palm Oil Plant photo-2
Latest Technology for Palm Fruit Thresher in Modern Plant Palm Oil Plant photo-3
US$ 2000 - 90000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Doing Brand
Place of Origin:
China
Model Number:
Palm oil processing machine
Contact Supplier Request Quote Chat Now
Henan Doing Company
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao ,Shanghai, Tianjin ,Guangzhou port
Delivery Detail:
30 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Doing Brand
Place of Origin China
Model Number Palm oil processing machine
Certification CE&ISO
Weight depend on capacity
Dimension(L*W*H) depend on capacity
Production Capacity 1-2000T/D
Voltage 220v/380v
Usage Palm Oil
Power(W) depend on capacity
Automatic Grade Automatic
Product Description

1-120t/h latest technology for palm fruit thresher in Modern Plant palm oil plant



7504

Thresher machine is used to separate empty bunch and palm fruits, we have capacity from 1-120tph



Alongside the development of large-scale fully mechanised palm oil mills and their installation in plantations supplying the international edible oil refining industry, small-scale village and artisanal processing has continued in Africa. Ventures range in throughput from a few hundred kilograms up to 8 T FFB(fresh fruit bunch) per day and supply crude oil to the domestic market.

The general flow diagram is as follows:Palm oil processing machine | indonesia palm oil suppliers





No Main section Main machine
1 Fresh palm fruit bunch reception section Loading ramp
2 Sterilization section Sterilization tank
3 Threshing section Threshing Machine Platform
4 Digesting & Pressingsection Digester & Screw presser
5 Oilclarification section ClarificationTank
6 Fiber separation section Polishing drun
7 Palm kernel recovery section (1)Palm nut storage tank (2)Polishing drum (3)Nut grading screen (4) Palm nut Ripple mill (5)Separating column system (6)hydro cyclone equipment (7)Palm kernel drying bunker (8)Dry Palm kernel final storage warehouse
8
Nutsheller
9 Engine room Diesel generator
10 Boiler house Boiler
11 Water treatment
11 Effluent Treatment Plant

Palm oil production process:

Step 1 Bunch sterilization: FFB(fresh fruit bunch) have to be sent to sterilize to avoid AV (acid value) rise by sterilize the fatty enzyme with high temperature. At the mean time, sterilizing section can also soften the fruits, which benefits the threshing section and reduces the damage to kernel.

Palm oil processing machine | indonesia palm oil suppliers

Step2 Bunch threshing: The purpose of threshing is to separate the palm fruit from the FFB by rotary drum thresher.



750

Step 3 Fruit digestion:The purpose of digestion is to separate the pulp and kernel, soften the pulp with heat and to destroy the pulp cell structure.

Palm oil processing machine | indonesia palm oil suppliers

Step 4 Pulp pressing: After sterilizing, threshing and crashing, palm pulp become soft and the cell structure is broken. In another word, we can easily get the oil with spiral oil press, which is also called CPO(crude palm oil).

Palm oil processing machine | indonesia palm oil suppliers



5.Clarification system
Use vibrated sifting filter to remove residues like fiber in the crude palm oil, then the oil enter into the passivating tank.

6.Depericarping Station

The pressed palm fiber cake gets into the cake breaker then get into the winnowing system to separate the fiber and nut.

7.Kernel Recovery System

8.Palm kernel recovery machine

Then nut will be crushed to get shell and kernel. Through winnowing system and washing system to separate the shell and kernel. The shell can be used as fuel for boiler, the kernel will be dried for storage and sell to others or next processed into palm kernel oil by another plant(palm kernel processing plant ).

(1)Palm nut storage tank: used for storage the palm kernel

(2)Polishing drum: Used for polishing the palm nut and remove the residual fibre to get clean palm nut.

(3)Nut grading screen:classify palm nuts into different grades

(4)Ripple mill: Used for cracking the palm nut , cracking the hard shell of the palm nut and get the mixtures of palm kernel and shell.

(5)Separating column system &hydro cyclone equipment:separate the kernel from the shell

(6)Palm kernel drying bunker: drying finally palm kernels:finally the dryed palm kernels can be processed further via palm kernel oil expeller or directly sell to others.

(7)Dry Palm kernel final storage warehouse: Used for storage the dryed palm kernel.

Other Assistant Equipments of Palm Oil Mill

9.Boiler House:

10.Power House

11.Water Supply and Treatment (Including boiler water treatment)

12.Effluent Treatment Plant

The above is the mainly introduction of palm oil mill (suitable for capacity above 15tph). Any question about palm oil mill process flow chart diagram and any capacity palm oil processing machine , please feel free to contact Henan Doing Company. You will get more thank you think.


The process of this palm oil production line : FFB--Sterilizing---Threshing--Pressing--Clarifying--Filitering--Oil Drying-Crude palm oil.



the specification of crude palm oil



Item

Standard

Smell and taste

The original smell and taste of palm oil

Moisture and volatile matter (%)           ≤

0.20

Insoluble impurities (%)                            ≤

0.20

Acid value (mgKOH/g)                         ≤

4.0

Peroxide value (mmol/kg)                      ≤

7.5



 the specification of refined palm oil



Item

Standard

Color (Lovibond Cell 133.4mm)             ≤

R3.5  Y35

Smell and taste                                ≤

No smell and good taste

Transparence                                   ≤

Clear and transparent

Moisture and volatile matter (%)        ≤

0.05

Insoluble impurities (%)                         ≤

0.05

Acid value (mgKOH/g)                      ≤

0.20

Peroxide value (mmol/kg)                   ≤

5.0

Smoke point (°C)                             ≥

215

This is just a brief introduction of crude palm oil processing, and there’s still many details in crude palm oil processing.
