Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > SFP+ 10G 80km CWDM Optical Module, CWDM 1470nm~1610nm 10G CWDM SFP+ Transceivers
SFP+ 10G 80km CWDM Optical Module, CWDM 1470nm~1610nm 10G CWDM SFP+ Transceivers
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
2004
Annual Export Value:
US$10 Million - US$50 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Brand Compatible SFP-10G-SR 10GBASE SFP+ Modules Multimode Fiber 850nm 300M Optical TransceiverNegotiableMOQ: 1 -
Brand Compatible 10g Sfp zr 1550nm 120kmNegotiableMOQ: 1
-
Sfp-10g-lr Compatible 10Gbp/s 1310nm 10km 20km DOM SFP+ Module TransceiverNegotiableMOQ: 1
-
10G 40km 80km SFP DWDM Transceiver ModulesNegotiableMOQ: 1
-
Brand Compatible Sfp-10g-zr=NegotiableMOQ: 1
OEM SFP+ 10G 80km CWDM optical module, 1470nm~1610nm 10G CWDM SFP+ Transceivers
1.Description
- This SFP+ZR CWDM transceiver is designed to transmit and receive optical data over single mode optical fiber for link length 80km.
- The transceiver consists of two sections: The transmitter section incorporates a colded EML laser. And the receiver section consists of a APD photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.
2.Applications
- 10G Ethernet
- 10G Fiber Channel
- CWDM Networks
3.Features
- Compliant with SFF-8431,SFF-8432 and IEE802.3ae
- Wavelength selectable to ITU-T standards covering CWDM grid wavelengths
- Cooled EML transmitter and APD receiver
- Digital Diagnostic Monitor Interface
- Hot pluggable
- link length up to 80km
- 10GBASE-ZR, and 2G/4G/ 8G/10G Fiber Channel applications.
- Low power consumption
- Operating case temperature: 0 to 70 °C
5.Product list
| Part Number | Data Rate | Wavelenth | Distance | Package | Temp. | Source |
| XFP (10G) | ||||||
| RXFP-85192-SRD | 10G | 850 | 300M | XFP | 0~70 | VSCEL+PIN |
| RXFP-31192-LRD | 10G | 1310 | 10KM | XFP | 0~70 | EML+PIN |
| RXFP-55192-ERD | 10G | 1550 | 40KM | XFP | 0~70 | EML+PIN |
| RXFP-55192-ZRD | 10G | 1550 | 80KM | XFP | 0~70 | EML+APD |
| X2 (10G) | ||||||
| RX2-85192-SRD | 10G | 850 | 300M | X2 | 0~70 | VSCEL+PIN |
| RX2-31192-LRD | 10G | 1310 | 10KM | X2 | 0~70 | DFB+PIN |
| RX2-55192-ERD | 10G | 1550 | 40KM | X2 | 0~70 | EA-DFB+PIN |
| RX2-55192-ZRD | 10G | 1550 | 80KM | X2 | 0~70 | EA-DFB+APD |
| XENPAK (10G) | ||||||
| RXENPAK-85192-SRD | 10G | 850 | 300M | XENPAK | 0~70 | VSCEL+PIN |
| RXENPAK-31192-LRD | 10G | 1310 | 10KM | XENPAK | 0~70 | DFB+PIN |
| RXENPAK-55192-ERD | 10G | 1550 | 40KM | XENPAK | 0~70 | EA-DFB+PIN |
| SFP+ (10G) | ||||||
| RSFPP-85192-SRD | 10G | 850 | 300M | SFP+ | 0~70 | VSCEL+PIN |
| RSFPP-31192-LRD | 10G | 1310 | 10KM | SFP+ | 0~70 | DFB+PIN |
| RSFPP-55192-ERD | 10G | 1550 | 40KM | SFP+ | 0~70 | EML+PIN |
| DWDM XFP (10G) with DDMI, XX is C-Band and L-Band ITU, XX=17, 18, 19…, which 17=1563.86nm, 18=1563.05nm… | ||||||
| RDXFP-XX192-40D | 10G | XXXX.XX | 40KM | DWDM XFP | 0~70 | DFB+PIN |
| RDXFP-XX192-80D | 10G | XXXX.XX | 80KM | DWDM XFP | 0~70 | DFB+PIN |
| CWDM XFP(10G) with DDMI, XX=27, 29, 31…61, which 27=1270nm, 29=1290nm, and 61=1610nm | ||||||
| RCXFP-XX192-10D | 10G | (1270-1330nm) | 10KM | CWDM XFP | 0~70 | DFB+PIN |
| RCXFP-XX192-40D | 10G | (1470-1610nm) | 40KM | CWDM XFP | 0~70 | EML+PIN |
| CWDM SFP+(10G) with DDMI, XX=27, 29, 31…61, which 27=1270nm, 29=1290nm, and 61=1610nm | ||||||
| RCSFPP-XX192-10D | 10G | (1270-1330nm) | 10KM | CWDM SFP+ | 0~70 | DFB+PIN |
| RCSFPP-XX192-40D | 10G | (1270-1330nm) | 40KM | CWDM SFP+ | 0~70 | DFB+PIN |
More to be list.....
Payment & Shippment
1.Payment
2.Shipment:by Sea,by Air,by Express:DHL/UPS/Fedex/EMS/TNT etc
.
