12 Core Black GYXTW Single Mode G652D Outdoor Fiber Optic Cable 12 Core GYXTW Fiber Optic Cable
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
1990
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
4 Cores Single Mode G652D GYXTW Aerial Outdoor Steel Wire Fiber Optic Cable FTTH GYXTW 4 Core Fiber Optic CableNegotiableMOQ: 1 -
4 Cores Single Mode G652D GYXTW Aerial Outdoor Steel Wire Optical Fiber Cable FTTH 4 Core Gyxtw Fiber Optic CableNegotiableMOQ: 1
-
PVC LSZH FTTH 2 Core Ftth Drop Cable Lszh Sheath Bow Type Ftth Drop Cable Outdoor Fiber Optic Drop Cable Gjyxfch-2b6NegotiableMOQ: 1
-
Indoor Duplex GJFJBV SM MM Flat Fig. 8 Zipcord Fiber Optic Cable LSZH PVC Fiber Patch Cord Cable 2 Core Fiber Optic CableNegotiableMOQ: 1
-
FTTH GYXTW Loose Tube Single Mode Outdoor Aerial Fiber Optical CableNegotiableMOQ: 1
Product Description
Fiber Count
(F)
|
Cable Diameter
(mm)
|
Cable Weight
(kgs)
|
Tensile Strength (N) |
Crush Strength (N) |
Min. Bending Radius |
Temperature Range
(℃)
|
||||||
Long term |
Short Term |
Long term |
Short Term |
Long term |
Short Term |
|||||||
2 |
8.0 |
78 |
600 |
1500 |
300 |
1000 |
10D |
20D |
-40~+60 |
|||
4 |
8.0 |
78 |
600 |
1500 |
300 |
1000 |
10D |
20D |
-40~+60 |
|||
6 |
8.0 |
78 |
600 |
1500 |
300 |
1000 |
10D |
20D |
-40~+60 |
|||
8 |
8.0 |
78 |
600 |
1500 |
300 |
1000 |
10D |
20D |
-40~+60 |
|||
10 |
8.0 |
78 |
600 |
1500 |
300 |
1000 |
10D |
20D |
-40~+60 |
|||
12 |
8.0 |
78 |
600 |
1500 |
300 |
1000 |
10D |
20D |
-40~+60 |
|||
1.High quality,long distance transmission fiber Steel Tape Armored,and Water-Resistant Brand NEW PE,or HDPE cable sheath
2.Standard fiber length 24km/roll and 48km/roll.
3.High quality PE/HDPE material cable sheath, very smooth surface, anti-UV, flame-Resistant
4.1, Standard production Line, strict SOP production Procedure
4.2, Attenunation test for each fiber by OTDR after production, and QC for every detail
4.3, 2km, 3km or 4km per durm Strong wood drum sealed with wood bars
4.4, Double steel tapes for better protection
4.5, Double or Triple layer loading in the containers Save space and save shipping cost
4.6,Wood brick under the drums to make surethe drums can not be rolled or moved in the containers
Related Products
Packing&Shipping
our services
1.Advanced production and testing equipment
2.Professional manufacturer, 100% tested.
3.Full compliance with ISO 9001:2008 quality management system
4.Our company has experienced professional team
5.Provide reliable solutions and satisfactory services
6.Warmly services with careful attentions.
7.Can provide your specific inquiry within 24 hours. Advanced production and testing equipment
Company Introduction
WeUnion Communication Technology Co., Ltd. is a professional manufacturer
focuses on development,production, and sales of fiber telecommunication product.
We provide Fiber Optic Cable, Fiber Patch cord, fiber pigtail, Optic PLC splitter, Fiber
Distribution Boxes and relevant products which are widely used in FTTX, LAN, WAN, G-Pon,
E-Pon Project. Our company has advance production and test equipments, strict production
and quality control system, and stable supply chain. We are fully compliant with ISO9001: 2008
quality management system, we guarantee that our products areIEC60794 and
Telcordia-GR-326-Core standard compliant, also compliant with our customers’ varied requirements.
Our company has rich experienced professional team and iscommitted to providing
customers with reliable solution and satisfactory services. Through continuous development and
expansion of our company, we now have customer around the world, especially in North America,
South America, Europe, andAsia. Our products and services have been well received by customers.
In the future, we will continue to provide customerswith safe and reliable FTTX solutions.
FAQ
Q1: When can I get the quotation back?
A:Generally, quotes will be replied within 24 hours or faster(weekends not included), however, a few of days would be taken for special ones.
Q2:How about the cable's quality ?
A: Our factory has dug in this industry for many years and sold to many countries in the world. We are fully compliant with ISO9001: 2008 quality management system, we guarantee that our products are IEC60794 and Telcordia-GR-326-Core standard compliant. We have a series of professional equipment and manufacturing instruments to make sure reliable quality of our products.
Q3: How do l assure that you are a reliable supplier?
A: We are the Assessed Supplier of . Alibaba as the third party to verify our factory and office to confirm we are a real and reliable supplier. If you are willing to verify that through the phone or video, you are welcome at any time.
Q4: Could the OEM be accepted and what's the MOQ?
A: Of course, your customization order is always welcomed. The MOQ Depends on different
