Lubricant Hydraulic Oil Filtration Machine Used Oil Recycling Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
1993
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mobile Vacuum Online Lubricating Oil Purifier Waste Oil Filtration Hydraulic Oil Filter MachineNegotiableMOQ: 1 -
Oil Supplier Machine Purifier Hydraulic Lubricating Oil Purification Machine Filter Machine for Oil PlantNegotiableMOQ: 1
-
Waste Oil Purifier Machine Clean Oil to Used Again and Again in High-Precision Hydrauli Lubrication EquipmentNegotiableMOQ: 1
-
Oil Purifier Vacuum Industrial Lubricants Oil Purifier Machine Filtration EquipmentNegotiableMOQ: 1
-
2021 Full Automotive Lubricant Oil Filtration MachineNegotiableMOQ: 1
Anti-Explosion Lubricant Oil Machine Oil Purifier / Factory Direct Oil Filter Machinery
Product Description
Product Name :
◆ TYA Lubricating Oil Purifier
Unqualified mechanical oil, hydraulic oil, compressor oil,
turbine oil, refrigerator oil
Features:
◆ The water separator uses high-molecular coalescing material as filtering medium, which integrates emulsification, dehydration and impurity removal.
◆ Strong ability to remove impurities: ultra-large area cylindrical precision filter element, with high filtration accuracy, easy installation and replacement.
◆ High-efficiency vacuum dehydration and degassing: Duplex-Stereo film evaporation technology
◆ Excellent heating system: carbon fiber electric heater with long service life, low heating surface load, linear temperature rise, preventing oil cracking, keeping oil uniform heating.
◆ Automatic control to realize unattended, safe and stable working.
◆ Safety interlock protection: oil pump, vacuum pump, heater interlock protection
◆ Humanized instructions: automatic design, and there are instructions such as oil temperature gauge, pressure gauge, vacuum gauge, filter pollution alarm, operating status and so on.
◆ This machine has the advantages of low noise, easy operation, long maintenance interval, low energy consumption, low operating cost, high oil filtration efficiency, long lifetime, etc.
◆ Strong ability to remove impurities: ultra-large area cylindrical precision filter element, with high filtration accuracy, easy installation and replacement.
◆ High-efficiency vacuum dehydration and degassing: Duplex-Stereo film evaporation technology
◆ Excellent heating system: carbon fiber electric heater with long service life, low heating surface load, linear temperature rise, preventing oil cracking, keeping oil uniform heating.
◆ Automatic control to realize unattended, safe and stable working.
◆ Safety interlock protection: oil pump, vacuum pump, heater interlock protection
◆ Humanized instructions: automatic design, and there are instructions such as oil temperature gauge, pressure gauge, vacuum gauge, filter pollution alarm, operating status and so on.
◆ This machine has the advantages of low noise, easy operation, long maintenance interval, low energy consumption, low operating cost, high oil filtration efficiency, long lifetime, etc.
Application:
◆ TYA Vacuum lubricating oil purifier mainly deals with unqualified mechanical oil, hydraulic oil, compressor oil, turbine oil,
refrigerator oil etc. It can quickly and effectively remove water, gas, impurities and volatiles (such as alcohol, gasoline,
ammonia, etc.) from oil. it restores oil viscosity, flash point and other performance indicators. The filtered oil is low
emulsification value, low water content, high cleanliness, which can be used again and again in high-precision hydraulic
lubrication equipment. TYA Oil Purifier is suitable for various kinds of lubrication purification and regeneration treatment in
petroleum, chemical, mining, metallurgy, power, transportation, machinery manufacturing, railway and other industries.
refrigerator oil etc. It can quickly and effectively remove water, gas, impurities and volatiles (such as alcohol, gasoline,
ammonia, etc.) from oil. it restores oil viscosity, flash point and other performance indicators. The filtered oil is low
emulsification value, low water content, high cleanliness, which can be used again and again in high-precision hydraulic
lubrication equipment. TYA Oil Purifier is suitable for various kinds of lubrication purification and regeneration treatment in
petroleum, chemical, mining, metallurgy, power, transportation, machinery manufacturing, railway and other industries.
Optional Device:
A- Optional PLC control.B- Oil pump set, vacuum pump set, filter element and electrical parts are selected imported brand products.
C- Flow meter, online moisture monitoring
D- Select the appropriate explosion-proof level according to the working environment (ExdII BT4 / ExdII CT4)
Oil Index After Treatment
Index | Unit | TYA-10 | TYA-20 | TYA-30 | TYA-50 | TYA-100 | TYA-150 | TYA-200 | TYA-300 | |||||||||
Flow rate | L/H | 600 | 1200 | 1800 | 3000 | 6000 | 9000 | 12000 | 18000 | |||||||||
Working vacuum | MPa | -0.06～-0.095 | ||||||||||||||||
Working Pressure | MPa | ≤0.4 | ||||||||||||||||
Working Temperature | ℃ | 20 ～80 | ||||||||||||||||
Power Supply | 380V 50HZ,3Ph (or According to user demand) | |||||||||||||||||
Working Noise | dB(A) | ≤65～80 | ||||||||||||||||
Heating Power | Kw | 24 | 24 | 24 | 30 | 48 | 72 | 96 | 120 | |||||||||
Total Power | Kw | 27 | 27 | 27 | 33 | 53 | 78 | 102 | 128.5 | |||||||||
Inlet / Outlet | mm | 25 | 25 | 25 | 32 | 40 | 50 | 50 | 65 | |||||||||
Weight | kgs | 450 | 480 | 500 | 550 | 650 | 800 | 1000 | 1300 | |||||||||
Dimension(MM) | L | 1550 | 1550 | 1550 | 1650 | 1750 | 1800 | 1900 | 2100 | |||||||||
W | 1100 | 1100 | 1100 | 1200 | 1250 | 1500 | 1600 | 1800 | ||||||||||
H | 1650 | 1650 | 1650 | 1750 | 1750 | 1850 | 1950 | 1950 | ||||||||||
After Purification | ||||||||||||||||||
Demulsification value | min | ≤15/min(GB/F7035) | ||||||||||||||||
Water Content | ppm | ≤80 | ||||||||||||||||
Gas Content | % | ≤0.1 | ||||||||||||||||
