High Quality Used Oil Vacuum Refinery Machine Waste Transformer Oil Recycling Plant Oil Machine
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Movable Oil Machine Filtration Equipment Oil Recycling Industrial Vacuum Filtration Other Cleaning Equipment
-
Easy Installation Waterproof Transformer Oil Filtration Machine To Meet Used Transformer Field Work Requirements
-
Well Made Trailer Style Transformer Oil Filtration Unit For Transformer Insulating Oil Filter
-
Chinese Manufacturer Transformer Oil Purifier Machine Mineral Oil Filtration Machine With Movable Wheels
-
Mobile Oil Filtration Machine Insulating Oil Treatment Machine For Transformer
-
Best Price Transformer Oil Filter Machine For Mineral Electrical Insulating Oil Filtering
Product Description
Product Description
Specification
Index | Unit | ZYD-30 | ZYD-50 | ZYD-100 | ZYD-150 | ZYD-200 | ZYD-250 | ZYD-300 | ||||||||
Flow Rate | L/H | 1800 | 3000 | 6000 | 9000 | 12000 | 15000 | 18000 | ||||||||
Working Vacuum | MPa | -0.08～-0.099 | ||||||||||||||
Working Pressure | MPa | ≤0.4 | ||||||||||||||
Working Temperature | ℃ | 20 ～80 | ||||||||||||||
Power Supply | 380V 50HZ,3Ph (or According to user demand) | |||||||||||||||
Working Noise | dB(A) | ≤65～85 | ||||||||||||||
Heating Power | Kw | 24 | 30 | 60 | 90 | 120 | 150 | 180 | ||||||||
Total Power | Kw | 27.5 | 35 | 65 | 96.5 | 128 | 162 | 185 | ||||||||
Inlet / Outlet | mm | 25 | 32 | 40 | 50 | 50 | 65 | 65 | ||||||||
Weight | kgs | 550 | 650 | 880 | 1000 | 1250 | 1550 | 1800 | ||||||||
Dimension(MM) | L | 1500 | 1550 | 1650 | 1800 | 2000 | 2150 | 2400 | ||||||||
W | 1450 | 1450 | 1550 | 1650 | 1750 | 1750 | 1800 | |||||||||
H | 1700 | 1750 | 1800 | 1900 | 2100 | 2200 | 2200 | |||||||||
After Purification | ||||||||||||||||
Breakdown Voltage | KV | ≥ 70 | ||||||||||||||
Water Content | ppm | ≤ 3 | ||||||||||||||
Gas Content | % | ≤ 0.1 | ||||||||||||||
Particles | µm | ≤ 1 | ||||||||||||||
Features:
◆ The vacuum system uses the roots pump as the main pump and the rotary vane vacuum pump as the primary pump. Fast start-up, large pumping speed, stable performance, and high ultimate vacuum of less than 5Pa.
◆ Double horizontal vacuum separators, combined with Duplex-Stereo film evaporation technology
◆ Strong ability to remove impurities: ultra-large area cylindrical precision filter element, with high filtration accuracy, easy installation and replacement.
◆ Low-load heating: Adopt advanced internal and external double-tube heat radiation indirect heating technology.
◆ Automatic controlto realize unattended, safe and stable working.
◆ Safety interlock protection for oil pump, vacuum pump, heater,keep safely working
◆ Low noise, easy operation, long maintenance interval, low energy consumption, low operating cost
◆ It can be used together with the insulation oil regeneration device, which has the effect of decoloring, deacidification, deoxidation and removing free carbon and other harmful substances from the oil.
◆ The vacuum system uses the roots pump as the main pump and the rotary vane vacuum pump as the primary pump. Fast start-up, large pumping speed, stable performance, and high ultimate vacuum of less than 5Pa.
◆ Double horizontal vacuum separators, combined with Duplex-Stereo film evaporation technology
◆ Strong ability to remove impurities: ultra-large area cylindrical precision filter element, with high filtration accuracy, easy installation and replacement.
◆ Low-load heating: Adopt advanced internal and external double-tube heat radiation indirect heating technology.
◆ Automatic controlto realize unattended, safe and stable working.
◆ Safety interlock protection for oil pump, vacuum pump, heater,keep safely working
◆ Low noise, easy operation, long maintenance interval, low energy consumption, low operating cost
◆ It can be used together with the insulation oil regeneration device, which has the effect of decoloring, deacidification, deoxidation and removing free carbon and other harmful substances from the oil.
Company Profile
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
Q1. Can you please offer sample?
A: Sorry, our products are customized one-to-one according to customer needs, so samples cannot be provided.
Q2. What is your packing method?
A: Generally, our goods packed by wooden box.
Q3. What is your terms of payment?
A: Generally, we use T/T, 30% in advance, balance pay after the machine finish.
Q4. How about your delivery time?
A: Generally, it will take 5 to 10 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you customized goods for us?
A: Yes, we can customized by your samples or technical drawings.
Q6. If you have any inspection or test for your goods before delivery?
A: Yes, we do the inspection and test before finished goods.
Q7. Can we visit your factory?
A: Yes, we warmly welcome your visiting, and can pick up you at airport or train station.
A: Sorry, our products are customized one-to-one according to customer needs, so samples cannot be provided.
Q2. What is your packing method?
A: Generally, our goods packed by wooden box.
Q3. What is your terms of payment?
A: Generally, we use T/T, 30% in advance, balance pay after the machine finish.
Q4. How about your delivery time?
A: Generally, it will take 5 to 10 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you customized goods for us?
A: Yes, we can customized by your samples or technical drawings.
Q6. If you have any inspection or test for your goods before delivery?
A: Yes, we do the inspection and test before finished goods.
Q7. Can we visit your factory?
A: Yes, we warmly welcome your visiting, and can pick up you at airport or train station.
