Home > Products > Current sensor > Split-Core current transformer T series SCT016TS
Split-Core current transformer T series SCT016TS
- 1000 per Month
- T/T Credit Card
You May Like
-
Made-in China waterproof high voltage low current transformer
-
High-precision Current sensing transformer Ferrite core
-
Current Sensor Split-Core Transformer SCT 010 016 018 024 036 045 060 070 Type
-
Customized Toroidal transformer for AC current machine
-
1:100/1:1000/1:1500/1:2000/1:3000 Zero Phase Current Sensor
-
30A 1000MV Toroidal Current Sensor CBCT In Nano Core 1500:1
Product Description
Product Name: SPLIT CORE CURRENT TRANSFORMER
Product Name | CT30 Series Split core small current transformer manufacturer | ||||
Model No. | CT30 Series | ||||
Rated Current | 50A | ||||
Max Current | 120A, 50Hz | ||||
Rated Frequency | 50/60 | ||||
Accuracy Class | 0.5, 1.0 | ||||
Current Ratio | 3000:1 | ||||
Load Resisitance | 20Ω | ||||
Central Hole Diameter | 16mm/0.63" | ||||
Overall Size | 46 x 34 x 66mm/1.81" x 1.34" x 2.60"(L*W*H) | ||||
Shell Material | Plastic | ||||
Color | Black | ||||
Frequency Band | 50Hz~60Hz | ||||
Dielectric strength | 3000VAC 2mA60s | ||||
Saturation Current | ≥120A 50Hz | ||||
Inductance | ≥15H (@50HZ,1V) | ||||
Linearty Error | 1% | ||||
Maximum error | 1.2 to 120A |
SHAANXI FULLSTAR ELECTRONICS CO.,LTD is specialized in electronics and magnetic components. We are professional Electronics manufacturing company with good reputation in the field. Our company keeps pace with update technologies and developing its capacity. As an ISO certified company we adhere to strict quality control system thus all products to meet RoHS Standard and industry international standards.
Fullstar electronics are always ready to provide customers with the best products and services. Sincerely look forward to establishing long term cooperation with you to create the brilliancy together.
We own an outstanding sale and service team and establish a huge marketing network covering market both home and aboard.
Our operating policy is "Quality comes first, customer foremost".
Engaging, learning and mastering advanced technology, Fullstar excellent team provide high quality products, quick delivery, strong technical support & best service and would help our customers achieve the maximum value.
1. Q: Why choose us?
A: Fullstar has been mamufacturing customized inductors for more than 24 years.
2. Q: Do you have any certificates?
A: We have CE, RoHS, CCC, CQC, ISO9001:2015 Certification.
3. Q: How about your products quality inspection?
A: We have professional QA and QC teams. 100% quality inspection is performed before shipment.
4. Q: Can you use our logo?
A: We accept OEM and ODM production.
5. Q: What's your quality guarantee?
A: We repair or replace parts within 18months if necessary.
