1000uh 1mh SMD Semi Shielded power Inductor
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
Ceramic Wirewound Unshielded Chip Inductors
-
Customized High Current SMD Shielded Power Molding Choke Inductor Coil 47uh
-
Copper Wire Winding Coil Ferrite Rod Core Choke Coil High Frequency Inductor
-
2R7 27uH 6R8 6.8uH 10uH SMD Chip Bead Inductor for signal line 1210 size 28 ohm 4A
-
Competitive factory price SMD Shielded Power Inductor with RoHS
-
China Factory Adjustable Inductor IFT Coil /Tuneable Inductor
Product Description
Product Description
22uh SMD Semi Shielded Inductor Magnetic Epoxy SMT Low Profile Semi Sealed High Current Inductor
Power inductor, is also called high current inductor. It is an attribute of the closed loop. When the current passes through coil of the inductor, the inductor forms a magnetic field induction in the coil, and the induced magnetic field will generate an induced current to resist the current passing through the coil. The function of the power inductor in the circuit is to produce a changing magnetic field when passing through the unstable current, which in turn affects the current.
Product name | 1000uh 1mh SMD Semi Shielded power Inductor | ||||
Brand name | Fullstar | ||||
Model Number | SNR 6045 series | ||||
Fuction | Power line filter/Signal line filter/Energy saving/Voltage step-up etc/Choke etc | ||||
Components | Ferrite core, Copper wire, base | ||||
Inductance Range | 10uH-1H | ||||
DCR Range | Depends on customers' request | ||||
Certification | ISO9001:2015, ROHS | ||||
Package | BOXES | ||||
Lead time | 2-4 weeks. | ||||
Product features | Low profile and small inductors Magnetically shielded construction and high current Ideal for DC-DC converter choke coil for portable equipments ( DVDs , DSC , Cellular , PDAs ) RoHS compliant option with lead free | ||||
SMD High Current Semi-Shielded Inductor
*high current *high heat resistance
Refining Production Ensures High Quality
Main Product Features
Stable Quality | High flexibility | |
1. Semi-automatic mechanized production shortens personnel training and reduces process defects. 2. Reduce manual use and cost | Master the core technology of the whole process, provide technical solutions according to the different performance and specifications for customers. | |
Five major features of this SMD inductor | ||
1. The flat bottom surface is suitable for surface mounting, environmentally friendly and lead-free. 2. Excellent surface strength, good solderability and heat resistance. 3. High Q value and low impedance. 4. Low magnetic leakage, low direct resistance and high current resistance. 5. Braided packaging is available to facilitate automated assembly. | ||
Datasheets of SNR 8040 Series semi-Sheilded SMD inductor
Advanced Production and test equipments
