Digital Voltage Protector 40A 60A din rail Adjustable Protection Over Under Automatic High Low Voltage Protect relay protective
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
digital Voltage Relay 40A 60A 63A din rail Adjustable Protection Over Under Automatic High Low Voltage Protect Protection
-
63A Leakage Protection Circuit Breaker Over And Under Voltage Over Current Leakage Protection Surge Protect Protector
-
adjustable over voltage under voltage protector automatic 63A 40A RCBO Lightning Surge Power Leakage protector
-
60A 63A 380V Three Phase Din rail automatic recovery reconnect over voltage under voltage Three Phase voltage protector
-
3 three phase Voltage Current Relay Protector 63A 60A 220V 3P+N Over Under Voltage Relay Current limiter automatic protect
-
3P 63A 380V Three Phase Din rail automatic recovery reconnect over voltage under voltage protective protect protector relay
Product Description
Parameters
Functions:
1.Over-voltage protection
2.Under-voltage protection
3.Automatic recovery
4.Voltage display(voltage measurement)
5.Voltage Correction
Product Parameters:
| Model number | TVPS1-40ATVPS1-63A |
| Power supply | 230VAC 50/60Hz |
| Max.Loading power | 40A/63A |
Over-voltage protection value range:230V~300V-OFF
Over-voltage recovery voltage range:225V--295V
Over-voltage protection action time:0.1s~30s(default value:0.5s)
Over-voltage recovery delay time:1s~500s(default:30s)
5.Under-voltage protection value range:140V--210V --OFF(default:170V)
Under-voltage recovery voltage range:145V--215V (default:190V)
Under-voltage protection action time:0.1s~30s(default:0.5s)
Under-voltagerecovery delay time:1s~500s(default:30s)
6.Power-on delay time:1s~500s
7.Power consumption : <2W
8.Electric machinery life : 100,000 times
9.Installation:35mm DIN rail
Noted: When you first connect the product, you have to wait about 10 second(Power-on delay time:1s~500s(default:10s)),after the red light turn off, then the product will work.
Product display
