XL4005 DC-DC Adjustable Step-down 5A Power Supply Module,5A Large Current Large Power Step Down Module DSN5000 Beyond LM2596
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2009
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DC 12V-24V TPA3118 60W Mono Digital Audio Power Amplifier Board Amp Module Digital Amplifier BoardNegotiableMOQ: 1 -
JQX-59F 1Z DC 12V 80A SPDT General Purpose High Power Electromagnetic Relay 5 Pin, SPDT Mini General Purpose Power RelayNegotiableMOQ: 1
-
300W 20A DC-DC Buck Converter Step Down Module Constant Current LED Driver Power Step Down Voltage Module Electrolytic CapacitorNegotiableMOQ: 1
-
MY4NJ Electronic Micro Mini Electromagnetic Relay 5A 14PIN Coil 4DPDT With PYF14A Socket Base DC12V 24V AC110V 220V LEDNegotiableMOQ: 1
-
Trigger Cycle Timer Delay Switch 12 24V Circuit Board Dual MOS Tube Control Module Relay ModuleNegotiableMOQ: 1
Parameters
| Properties | non-isolated step-down module (BUCK) |
| Input voltage | 4-35V (input please try not to exceed 38V) |
| Output voltage | 1.25-32V continuously adjustable |
| Output Current | 0-5A, recommended in 4.5A |
| Output Power | 75W recommendations in the use of more than 50W, please add heat sink. |
| Operating temperature | -40 to + 85 degrees |
| Operating frequency | 180KHz |
| Conversion efficiency | up to 96% (efficiency of input and output voltage, current, pressure related) |
| Load regulation | S (I) ≤0.8% |
| Voltage Regulation | S (u) ≤0.8% |
| Power Indicator | YES |
| Short circuit protection | YES (limit current 8A) |
| Overtemperature protection | (automatically shut off the output after overtemperature) |
| Input Reverse Polarity Protection | None (if necessary please enter the string into the high current diode) |
| Installation | 2 3mm screws |
| Connection | Welding, V-IN is the input, V-OUT output |
Product display
