Connection

Single Phase

Display

LED Digital Screen

Measuring items

Voltage-V, current-A, active power-W, power factor-PF, frequency-Hz

Voltage Range AC/DC

5V-600V AC/DC(Switch the range automatically

Peak Voltage:700V AC/DC

Min test voltage:5V(Below 5V, can be customized )

Current Range AC/DC

10mA-20A AC/DC (Switch the range automatically)

 Peak Current:26A  AC/DC Min test current :10mA AC/DC( Below 10mA, can be customized)

Power Range(AC/DC)

0.1W-12KW

Power factor Range(AC)

0.001-1.000 Calculation method: Watt(W)/[voltage(V) current(A)]=Power Factor(PF)

Note: when t is DC signal, power factor PF display 1.000

The frequency range

45-65Hz Note: when it is DC signal, no frequency display

Communication Interface

Optional RS232 or RS485, Relay output function

Basic Accuracy

±(0.4% reading +0.1%range+1 digit)

Measuring Speed

Five times per second

Input Impedance

About 2MΩ(All voltage)

Power Supply

100~250V AC 50/400Hz, 100-300V DC

Volume and weight

355mm(L)*225mm(W)*112mm(H),Holesize:225mm(W)*99mm(H)≈1.7KG

Attachment

Power line, Operation Manual, Warranty Card
