GYT construction hoists We manufacture the parts in our machining workshops and laser cutting centers, our main objective is the optimization of raw materials to try to accomplish the goal of dry residue. We also have a type A energy-efficient compressor room,
migrating to a more sustainable and lower consumed LED technology. We recycle the materials and generated residues, and we send all our products in wooden or cardboard packaging.
We have an Export Department and an After-Sale Service created expressly for the international market and adapted to the needs it demands. Throughout our entire trajectory, we have participated (and continue to participate) in the main international trade fairs, which
allows us to learn about the trends in the sector. Our experience makes us today a world-class company, with a presence in 25 countries.
Characteristic |
Model |
Rated Loading |
Lifting Speed |
Motor Power |
|
Double cages |
SC200/200 |
2x2000kg |
33m/min |
2x(3x11kw) / 2x(3x8.5kw) |
|
SC150/150 |
2x1500kg |
33m/min |
2x(2x13kw) |
||
SC100/100 |
2x1000kg |
33m/min |
2x(2x11kw) |
||
Single cage |
SC200 |
2000kg |
33m/min |
3x11kw /3x8.5kw |
|
SC150 |
1500kg |
33m/min |
2x13kw |
||
SC100 |
1000kg |
33m/min |
2x11kw |
||
Double cages |
Low speed |
SC200/200D |
2X2000kg |
0-40m/min |
2x(3x11kw)/2x(3x8.5kw) |
SC100/100D |
2x1000kg |
0-40m/min |
2x(2x13kw) |
||
Mid speed |
SC200/200Z |
2x2000kg |
0-60m/min |
2x(2x23kw) |
|
SC100/100Z |
2x1000kg |
0-60m/min |
2x(2x15kw) |
||
Single cage |
Low speed |
SC200 |
2000kg |
0-40m/min |
3x11kw /3x8.5kw |
SC100 |
1000kg |
0-40m/min |
2x13kw |
||
Mid speed |
SC200 |
2000kg |
0-60m/min |
2x23kw |
|
SC100 |
1000kg |
0-60m/min |
2x15kw |
||
|Details Specification:
Item |
Construction hoist |
Model |
SC100/100/SC200/200 |
Rated capacity/per cage |
1000kg-2000kg |
Lifting speed |
0-63m/min,0-42m/min,0-33m/min |
Cage size |
3.2*1.5*2.4m |
Motor power |
3*15kw/3*11/2*15/3*18.5 |
Speed ratio |
1:18 /1:16 |
Invertor Power |
45 kW/37kw |
Safety device |
SAJ40-1.2/SAJ40-1.4/SAJ30-1.2 |
Mast section size |
0.65*0.65*1.508m |
Max. Installation height |
300m |
Cable type |
Cable basket/cable trolley |
Our company abides by the business philosophy of "quality first, customer first" to ensure product quality. We have rigorous production procedures, and each production process is carried out under strict quality inspection.Only after passing the inspection can they move on to the next procedure. At the same time, we insist on creating a neat, clean and safe working environment.
Completed safety measures Of Construction Hoist
1. Equiping with Anti-falling govenor
2. Electrical an Mechanical interlock: Door safety switches, Slack rope switch
3. Safety hook
4. Upper and bottom limit swithes, trap door limit switch
5. Overload protector
6. Bottom Buffer
7. Frequecy Conversion (Inverter) can be choose
8. PLC Control system can be choose
9. Level Calling system and Auto leveling device to be choose.
On large projects, clients benefit from our input at pre-planning stage to help determine exact lifting requirements. With our comprehensive service, we can advise clients on the most suitable access solution as well as providing the desired level of design input at any stage of the process.
We pay all our attention for CE approved Materials Passenger hoist Building Construction Hoist design and manufacturing.
