Warehouse Galvanized Welded Wire Storage Cage
Warehouse Galvanized Welded Wire Storage Cage Product Feature
1 Collapsible,save space when not in use,ideal for return journeys
2 Bright electro zinc plated finish
3 Standard half-hinged gate access
4 Long lasting,economical alternative to disposable packing
5 Open wire mesh design allows for full visibility for inventory checks,ventilation and cleanness.
6 Four-way entry for easy use with lift trucks
7 Application:widely used in agricultural,electronic equipment
Warehouse Galvanized Welded Wire Storage Cage Advantages:
1) With uniform specifications and fixed capacity, it makes the inventory easy to clear, sort and count, improving the efficiency .
2) Sturdy and durable, easy to carry and recyclable .
3) Improved wire containers can be stowed in the rack and assembly line and can also be stacked .
4) Wire mesh container with casters is movable .
5) Wire mesh container with PVC slab and steel slab can avoid the missing of small spare parts .
6) Wiremesh container with enlarged mesh space can be used to deposit paper boxes and goods .
Specification of wire mesh container
| Same design, different sizes | |||||
| Model No. | Exterior Dimension | Wire Guage | Grid Size | Loading Capacity |
Loaded in 1X40'GP |
| LxWxH(mm) | mm | mm | Kg | Sets | |
| W-1 | 1030X840X850 | 6 | 50X50 | 1300 | 470 |
| L-1 | 1030X840X850 | 6 | 50X50 | 800 | 470 |
| W-2 | 1230X1040X890 | 6.2 | 50X50 | 1700 | 320 |
| L-2 | 1230X1040X900 | 6.2 | 50X50 | 1200 | 320 |
| S-1 | 1230X1040X950 | 6.2 | 50X50 | 1700 | 320 |
| W-3 | 1030X840X500 | 6 | 50X50 | 800 | 470 |
| Material | Mild steel Q235 | ||||
| Application area | Warehouse, logistic, recycling industry | ||||
| Finish | Zinc/hot DIP galvanized/powder coating | ||||
| Remark | Costomized or OEM support | ||||
| Main features | 1. Collapsible-save space when not in use, ideal for return journeys 2. Standard half-hinged gate access 3. Long lasting, economical alternative to disposable packing 4. Open wire mesh design allows for full visibility for inventory checks, Ventilation and cleaness. |
||||
Warehouse Galvanized Welded Wire Storage Cage Remarks
Examples of custom-built Wire Mesh Container options:
1. Cap channel over wire perimeter for added protection
2. Square-Stack legs for secure stacking
3. Tags, labels, card holders
4. Casters, fork sleeves, runner bars
5. Dividers or security lids
6. Custom colors
7. Custom feet available.
8. Custom wire mesh size
9. Galvanized finish & powder coated finish
