Help CenterCVD Diamond Plates and Metallization
Related Products
CVD Diamond has been recognized an ideal material for various applications because of its outstanding properties which includes extreme hardness and strength, high thermal conductivity, low thermal expansion, excellent dielectric properties, resistance to chemical attack, and optical transmission over a wide spectral range. It can be widely used in complex tooling and machining processes, thermal-management applications, semiconductor industry and microwave engineering.
Thermal-Management Solutions
Polycrystalline CVD diamond is suitable for a variety of high-performance temperature-management applications. Specifications for thermal conductivity range up to 2000 W/m-K. At present, CVD diamond is used as mounts for high-power integrated circuits, laser diodes, GaN on Diamond (GOD) and heat spreaders for satellite based electronic systems.
Thermal Grade:
Standard Medium: ＞1200W/m.k
High: ＞1500W/m.k
Excellent:＞1800W/m.k (up to 2000W/m.k)
Tolerance of Thickness: ±25um
Flatness:Density: 3.5g/cm3
Young’s modulus: 1000-1100GPa
Growth side surface finish:Nucleation side surface finish:Standard Sizes
Double sides polished : Up to diameter 150 mm
As grown thickness: Between 0.3 mm and 1.5 mm
Polished thickness: Between 0.2 mm and 1.0 mm
