Specification Reference Standard |
IEC 60384-14 ; EN 60384-14 ; IEC UL60384 ; K 60384 |
Approved Monogram |
VDE / ENEC / IEC / UL / CSA / KC / CQC |
Subclass ; Rated Voltage(UR) |
X1 / Y1 /Y2 ; 400VAC / 300VAC/500VAC |
Capacitance Range |
10pF to 10000pF |
Voltage Proof |
4000VAC for 1min 2000VAC for 1min 1800VAC for 1min |
Capacitance Tolerance |
Y5P±10%(K) ; Y5U,Y5V±20%(M) measured at 25℃, 1Vrms, 1KHz |
Dissipation Factor (tgδ) |
Y5P,Y5U tgδ≤2.5% ; Y5V tgδ≤5% measured at 25℃, 1Vrms, 1KHz |
Insulation Resistance(IR) |
IR≥10000MΩ,1min,100VDC |
Operating Temperature |
-40℃ to +85℃ ; -40℃ to +125℃ |
Temperature Characteristic |
Y5P,Y5U,Y5V |
Flame Retardant Epoxy |
UL94-V0 |
Why Choose Us
1. Top-rank brand awareness and reputation in the industry
2. A professional manufacturer with over 30-year experience in electronic components
3. Awarded over 30 safety certificates from industrial power
4. Awarded ISO 9001 quality management system certificate, and ISO 14001 environmental system certificate
5. Fully automated production equipment running 24 hours to guarantee delivery
6. Company-owned 100 square meter laboratory, 200 testing equipment implementing reliability test for 56 days
7. Annual output of 2 billion pieces, which can circle the earth 10 times
8. Full range of products, over 10,000 models available in stock
9. Professional engineers assisting in model selection
10. Best pre-sales and after-sales service
11. Partnership with top 500 automotive electronics companies, e.g. BYD, Geely, FAW Motor etc.
12. Providing services for 1000+ power supply manufacturing companies each year
13. Trading with countries and regions worldwide
Q: What is a safety capacitor?
A: Safety capacitors are used in such occasions that after the capacitor fails: it will not cause electric shock and will not endanger personal safety. It includes X capacitors and Y capacitors. The x capacitor is the capacitor connected between the two lines of the power line (LN), and metal film capacitors are generally used; the Y capacitor is the capacitor connected between the two lines of the power line and the ground (LE, NE), and usually appears in pairs. Due to the limitation of leakage current, the Y capacitor value cannot be too large. Generally, the X capacitor is uF and the Y capacitor is nF. The X capacitor suppresses differential mode interference, and the Y capacitor suppresses common mode interference.
Q: Why are some capacitors called safety capacitors?
A: The "safety" in safety capacitors does not refer to the capacitor material, but that the capacitor has passed the safety certification; in terms of material, the safety capacitors are mainly CBB capacitors and ceramic capacitors.
