Parameter | ||
Proximity Switch |
IM12 DC3-wires standard distance |
|
Standard detection object |
12mm×12mm×1mm (Fe360 carbon steel) |
|
Detection distance |
embedded |
2mm±10% |
exposed |
4mm±10% |
|
Hysteresis |
≤15% |
|
Set distance |
embedded |
0-1.6mm |
exposed |
0-3.2mm |
|
Supply voltage |
10~30V DC |
|
Un-load current |
Max.5mA |
|
Voltage drop |
Max.1.4V |
|
Switch frequency |
embedded |
500Hz |
exposed |
500Hz |
|
Control output |
Transistor output, open collector |
|
Resistive load |
Max.200mA |
|
Insulation resistance |
Min.20MΩ(at 500VDC/1000VDC) |
|
Withstand voltage |
500VDC/1000VDC |
|
Anti-vibration |
≤10~55Hz sweep frequency(Range:1mm) |
|
Shock resistance |
Detection head:300m/s² about30G，housing:1000m/s² about100G |
|
Indicator |
Operation indicator: yellow |
|
Protection circuit |
Over voltage 、short circuit and reverse polarity protection |
|
Ambient temperature |
－25℃~70℃ (No-freezing) |
|
Storage temperature |
－30℃~80℃ (No-freezing) |
|
Humidity |
35~95%RH |
|
Housing material |
Cr plated on CU |
|
Thread specification |
M12×1 |
|
Cable |
Φ4, 3×0.2mm² |
|
Protection rating |
IP67 (IEC) |
|
Model | ||
Installment |
Product Model |
Output Mode |
|
Embedded type |
IM12B-02-NO |
NPN Normal open(NO) |
IM12B-02-NC |
NPN Normal close(NC) |
|
IM12B-02-PO |
PNP Normal open(PO) |
|
IM12B-02-PC |
PNP Normal close(PC) |
|
|
Exposed type |
IM12N-04-NO |
NPN Normal open(NO) |
IM12N-04-NC |
NPN Normal close(NC) |
|
IM12N-04-PO |
PNP Normal open(PO) |
|
IM12N-04-PC |
PNP Normal closse(PC) |
|
