Product Parameters | |
Photoelectric sensor | PS18T |
Detection type | Opposed type |
Detection object | MinΦ18mm opaque object |
Detection distance | 20m |
Supply voltage | 10-30v DC |
No-load current | Emitter: Max.12mA; Receiver: Max.7mA |
Response time | Max.4ms |
Light | Infrared LED(850nm) |
Action mode | Selecting Light On/Dark On on product model basis |
Control output | NPN open collector，Load voltage: Max.30VDC， Load current: Max.100mA，Voltage drop: Max.3.0VDC； |
PNP open collector，Output voltage: supply voltage-1.5V， Load current: Max.100mA； | |
Indicator | Emitter Power indicator: Green；Receiver Action indicator: Red |
Protection circuit | Short-circuit protection, Reverse polarity protection |
Ambient brightness | Sunlight: Max.60000lux Fluorescent: Max.3000lux |
Ambient temperature | －30℃~60℃ (No-freezing)，Storage: －40℃~80℃ |
Ambient humidity | 0~90%RH |
Housing material | Housing: Pc +ABS Wire: PVC |
Shape and size | As dimension |
Cable | Emitter :black , Receiver: Grey |
Protection rating | IP67 (IEC) |
Accessory | Screw |
Model | ||
Installation | Product Model | Detection Distance |
Opposed type | PS18T-2ND | 20m |
PS18T-2NL | 20m | |
PS18T-2PD | 20m | |
PS18T-2PL | 20m | |
