Galvanized Razor Wire Concertina Thorn Wire BTO22 Type for Outdoor Using From China Supplier
US$ 1 - 10
MOQ: 1 Roll
Key Specifications
Get Latest Price
Place of Origin:
China
Material:
Galvanized Iron Wire
Type:
Other
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
15 days
Related Products
-
Anti Thief Army Security Hot Dipped Razor Barbed Wire Razor Tape Wire 450mm Coil SizeUS$ 1 - 10MOQ: 1 Roll -
High Quality 500mm Coil Size BTO 22 Razor Wire Fence Concertina Blade WireUS$ 1 - 10MOQ: 1 Roll
-
10kg Per Roll With Coil 500mm OD Medium Blade 22MM Length BTO 22 Razor Wire FenceUS$ 1 - 10MOQ: 1 Roll
-
Constantine Razor Wire Fence BTO -22 Blade 450mm Coil Diameter From China Used on Security UsageUS$ 1 - 10MOQ: 1 Roll
-
Bto 22 Razor Blade Fencing Razor Ribbon Wire Coil Made in ChinaUS$ 1 - 10MOQ: 1 Roll
Place of Origin
China
Material
Galvanized Iron Wire
Type
Other
Application
Fence Mesh
Wire Gauge
2.5mm
Material
Galvanized Iron Wire
1. introduction
* This razor wire, suitable for all types of outdoor use, will be a perfect choice for protecting your fields and property. It could even be used to secure military sites, prisons and government agencies
* The sturdy barbed wire is already coiled and has 3 clips on each loop, which results in a tubular shape with gaps that are too small for a person to climb through
* This will keep unwanted guests out of your property. The razor wire can be wound around the top of your property fence for added security
* Made of high-quality galvanised steel, our razor wire is weather- and water-resistant, and highly durable
* The sturdy barbed wire is already coiled and has 3 clips on each loop, which results in a tubular shape with gaps that are too small for a person to climb through
* This will keep unwanted guests out of your property. The razor wire can be wound around the top of your property fence for added security
* Made of high-quality galvanised steel, our razor wire is weather- and water-resistant, and highly durable
2.Common specifications
| Specfication | Thickness | Wire Dia. | Barb Length | Barb Width | Barb Spacing |
| BTO-10 | 0.5±0.05 | 2.5±0.1 | 10±1 | 13±1 | 26±1 |
| BTO-12 | 0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 26±1 |
| BTO-18 | 0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 33±1 |
| BTO-22 | 0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 34±1 |
| BTO-28 | 0.5±0.05 | 2.5 | 28 | 15 | 45±1 |
| BTO-30 | 0.5±0.05 | 2.5 | 30 | 18 | 45±1 |
| CBT-60 | 0.6±0.05 | 2.5±0.1 | 60±2 | 32±1 | 100±2 |
| CBT-65 | 0.6±0.05 | 2.5±0.1 | 65±2 | 21±1 | 100±2 |
| Concertina Coil Specification | |||||||
| Coil Diameter | 300mm | 450mm | 730mm | 730mm | 980mm | 980mm | 1250mm |
| (12inch) | (18inch) | (28inch) | (36inch) | (36inch) | (36inch) | (50inch) | |
| Recommended Stretch Length | 4m | 10m | 15-20m | 10-12m | 10-15m | 8m | 8m |
| Coil Diameter When Stretched | 260mm | 400mm | 600mm | 620mm | 820mm | 850mm | 1150mm |
| Spiral Turns Per Coil | 33 | 54/55 | 54/55 | 54/55 | 54/55 | 54/55 | 54/55 |
| Clips Per Spiral | 3 | 3 | 3 | 5 | 5 | 7 | 9 |
3.Popular specification
Most Population Hot Dipped Galvanized BTO22 Razor Barbed Wire for Shipping Protect is named as its Hot Dipped Galvanized Material and the Razor blade style is BTO22.
From the material it divided into Electric Galvanized Razor Barbed Wire, Hot Dipped Galvanized Razor Barbed Wire, High Galvanized Razor Barbed Wire.
Compare the three material quality:
Electric Galvanized Razor Barbed Wire
