Anti Climb Mesh BTO-22 Single Razor Concertina Barbed Wire from china supplier
BTO-22 Razor Wire Description
BTO - 22 razor wire is common and the most popular a kind of blade type, its length is 22 mm, belong to the scope of medium length, due to the shape of a trapezoid, the sides of the blade is very sharp, have a very good resist function on invasive, forced crossing can cause physical harm, and even bleeding, many thieves or prisoners.The blade has a good protective effect on the internal staff, which is a good choice for many people.
BTO-22 Razor Wire Application
The Spiral Razor Wire is connected by the wire connecting clamp and the longitudinal tensile reinforcement fixed on the bracket. Longitudinal tensile reinforcement is used to connect with stents Φ 2.5 mm cold drawn tight fixed after galvanized steel wire round 2. The support is arranged at the column and mid-span of 3m protective fence, where the span is arranged into the upper part of the column, and the support and protective fence are connected by bracket hoop, for the protective fence with metal mesh already installed.Stinging cage directly use cold drawn Φ 2.5 mm galvanized steel wire or stinging connection card buckle fixed on the metal mesh horizontal slice and wire.
BTO-22 Razor Wire Technical Data
| Razor type | BTO-10, 11, 12, 22, 28, 30 CBT-60, 65 |
| Material | electro galvanized, hot dipped galvanized, pvc coated, stainless steel |
| Color | silver, green, black or as ur requirment |
| Blade thickness | 0.3mm - 0.6mm |
| Wire dia | 2.5mm - 2.8mm |
BTO-22 Razor Wire Parameter
| Form | spiral type, straight type |
| Model Number | BTO-22 |
| Blade Length | 22mm+-1mm |
| Blade Width | 15mm+-1mm |
| Blade Distance | 34mm+-2mm |
| Blade Thickness | 0.3mm+-0.05mm |
| Core Diameter | 2.5mm+-0.1mm |
| Outer Diameter | 50cm (10m/10kg) |
| Overlay Length | 10m+-0.5m (Normal stretch cover of 10 meters, can lengthen or shorten the cover) |
