Mercury conductive slip ring and rotary connector - the perfect substitute for the traditional slip ring to solve the problems of the traditional slip ring. The slip ring system is made of special sealing, insulation and conductive technology, and its shell is made of anodized aluminum alloy or stainless steel. The slip ring system is an ideal product for transmitting signal and controlling current. It is suitable for fields where the traditional slip ring is not competent (such as high speed, low impedance and low interference). The product is compact and durable without maintenance
Notes:
1. The service temperature shall not exceed 60 ºC, ambient temperature + self heating (rotation + power on)
2 when installing in the vertical direction, keep the u p upward, and keep it upward when saving.
3. Do not be eccentric when installing the rotary connector on the axis. It is best to use the 3-point buckle mode when installing the buckle screw.
4. Do not weld and heat the rotary connector itself or the copper terminal.
5. The special connection terminal cannot be used repeatedly.
6. If the rotating body vibrates, its service life will be reduced.
7. The connector can be fixed after the shell or plastic part is installed into the axis, and then pull the rotating part with the inserted terminal wire. One end is fixed on the axis and the other end is floating on the external fixed part, but it can never bear the weight.
If the above matters are not observed, the rotary connector will be damaged to varying degrees or reduce the service life.
| Model | A1H25S | A1H25ST | A1H25PS | A1H35S | A1H50S | A1H50PS | A1H65S | A1H65PS | A1H90PS | A1H150PS | A1H300PS |
| Conductor Poles | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Current (A) | 250 | 250 | 250 | 350 | 500 | 500 | 650 | 650 | 900 | 1500 | 3000 |
| AC/V | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A |
| Frequency (MHZ) | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 |
| Maximum (RPM) | 1200 | 1200 | 1200 | 800 | 300 | 300 | 200 | 200 | 200 | 100 | 60 |
| Working temperature(ºC) | -30~60 | -30~60 | -30~60 | -30~60 | -30~60 | -30~60 | -30~60 | -30~60 | -30~60 | -30~60 | -30~60 |
| Rotational torque (cm) | 250 | 250 | 250 | 300 | 700 | 700 | 1000 | 1000 | 1100 | 2000 | 3000 |
