China Wheel Ball Roller Rolling Bearing Fast Delivery Turbine Bearing NU2307 Cylindrical Roller Bearing Motor Reducer Machine Tool Spindle Roller Bearings

China Wheel Ball Roller Rolling Bearing Fast Delivery Turbine Bearing NU2307 Cylindrical Roller Bearing Motor Reducer Machine Tool Spindle Roller Bearings thumbnail-1
China Wheel Ball Roller Rolling Bearing Fast Delivery Turbine Bearing NU2307 Cylindrical Roller Bearing Motor Reducer Machine Tool Spindle Roller Bearings thumbnail-2
China Wheel Ball Roller Rolling Bearing Fast Delivery Turbine Bearing NU2307 Cylindrical Roller Bearing Motor Reducer Machine Tool Spindle Roller Bearings thumbnail-3
China Wheel Ball Roller Rolling Bearing Fast Delivery Turbine Bearing NU2307 Cylindrical Roller Bearing Motor Reducer Machine Tool Spindle Roller Bearings thumbnail-4
China Wheel Ball Roller Rolling Bearing Fast Delivery Turbine Bearing NU2307 Cylindrical Roller Bearing Motor Reducer Machine Tool Spindle Roller Bearings thumbnail-5
China Wheel Ball Roller Rolling Bearing Fast Delivery Turbine Bearing NU2307 Cylindrical Roller Bearing Motor Reducer Machine Tool Spindle Roller Bearings photo-1
China Wheel Ball Roller Rolling Bearing Fast Delivery Turbine Bearing NU2307 Cylindrical Roller Bearing Motor Reducer Machine Tool Spindle Roller Bearings photo-2
China Wheel Ball Roller Rolling Bearing Fast Delivery Turbine Bearing NU2307 Cylindrical Roller Bearing Motor Reducer Machine Tool Spindle Roller Bearings photo-3
China Wheel Ball Roller Rolling Bearing Fast Delivery Turbine Bearing NU2307 Cylindrical Roller Bearing Motor Reducer Machine Tool Spindle Roller Bearings photo-4
China Wheel Ball Roller Rolling Bearing Fast Delivery Turbine Bearing NU2307 Cylindrical Roller Bearing Motor Reducer Machine Tool Spindle Roller Bearings photo-5
US$ 0.1 - 50 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
China factory non brand/ SKF/ KOYO/ Timken/ INA/ NSK/ NTN
Place of Origin:
China
Model Number:
NU 1022 EM NU 1024 EM NU 1026 EM NU 1028 EM NU 1030 EM NU 1032 EM NU 1034 EM NU 1036 EM NU 1038 EM NU 1040 EM NU 1044 EM NU 1048 EM NU 1052 EM NU 1056 EM NU 1060 EM NU 1064 EM NU 1068 EM NU 1072 EM NU 1080 EM
Contact Supplier Request Quote Chat Now
Tianjin DSR Bearing Co.,Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin port
Delivery Detail:
3 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name China factory non brand/ SKF/ KOYO/ Timken/ INA/ NSK/ NTN
Place of Origin China
Model Number NU 1022 EM NU 1024 EM NU 1026 EM NU 1028 EM NU 1030 EM NU 1032 EM NU 1034 EM NU 1036 EM NU 1038 EM NU 1040 EM NU 1044 EM NU 1048 EM NU 1052 EM NU 1056 EM NU 1060 EM NU 1064 EM NU 1068 EM NU 1072 EM NU 1080 EM
Number of Row Single Row
Seals Type Open/ ZZ/ RS
Precision Rating P0 P6 P5 P4
Outside Diameter 10, 150
Bore Size 5, 100





Cylindrical roller bearings — for high radial forces and high speeds


NU

Two solid ribs on the outer ring and one inner ring without ribs make possible axial displacement in both directions.

NJ

Two solid ribs on the outer ring and one solid rib on the inner ring make possible guidance in the axial direction.

NUP

Two solid ribs on the outer ring, a solid rib on the inner ring, and a loose rib washer make possible the use as a locating bearing and axial guidance in both directions.

N

Two solid ribs on the inner ring and one outer ring without ribs make possible axial displacement in both directions.







Features


    • suitable for high radial load capacities and high speeds

    • series with smaller outside diameter in relation to inside diameter than series 2, 3, 22 and 23

    • lighter and suitable for higher speeds than series 2, 3, 22 and 23

    • Variant NU: floating bearing. axially displaceable due to ribless inner ring

    • cage material: brass. Special strength and durability under extreme conditions such as shock loads and vibrations,

    • high acceleration forces and lack of lubrication



NU series
Model d mm D mm H mm W kg
NU 1022 EM 110 170 28 2.3
NU 1024 EM 120 180 28 3.5
NU 1026 EM 130 200 33 3.84
NU 1028 EM 140 210 33 4.62
NU 1030 EM 150 225 35 4.8
NU 1032 EM 160 240 38 5.86
NU 1034 EM 170 260 42 8.2
NU 1036 EM 180 280 46 10.5
NU 1038 EM 190 290 46 11
NU 1040 EM 200 310 51 14.3
NU 1044 EM 220 340 56 19
NU 1048 EM 240 360 56 20.4
NU 1052 EM 260 400 65 29.4
NU 1056 EM 280 420 65 33.4
NU 1060 EM 300 460 74 44.4
NU 1064 EM 320 480 74 47
NU 1068 EM 340 520 82 65
NU 1072 EM 360 540 82 67.7
NU 1080 EM 400 600 90 92.5
Product Tags: motor bearing , Reducer bearing , Machine tool spindle bearing , bearing , bearings , roller bearing , rolling bearing , wheel bearing , cylindrical roller bearing
