Dixell High Quality Digital Display Remote Cold Temperature Controller Xr06cx-5n0c1 Agent

Housing: self extinguishing ABS.
Case: frontal 32x74 mm; depth 60mm;
Mounting: panel mounting in a 71x29mm panel cut-out
Protection: IP20; Frontal protection: IP65
Connections: Screw terminal block  2,5 mm2 wiring.
Power supply: according to the model 230Vac 10%, 50/60Hz --- 110Vac 10%, 50/60Hz
Power absorption: 3.5VA max
Display: 2 digits, red LED, 14,2 mm high; Inputs: Up to 2 NTC.
Digital input: free voltage contact
Relay outputs: compressor SPST 8(3) A, 250Vac; SPST 16(6)A 250Vac or 20(8)A 250Vac
defrost: SPDT 8(3) A, 250Vac
fan: SPST 8(3) A, 250Vac or SPST 5(2) A
Data storing: on the non-volatile memory (EEPROM).
Kind of action: 1B; Pollution degree: 2;Software class: A.;
Rated impulsive voltage: 2500V; Overvoltage Category: II
Operating temperature: 0÷60 °C;Storage temperature: -25÷60 °C.
Relative humidity: 2085% (no condensing)
Measuring and regulation range: NTC -40÷110°C;
Resolution: 0,1 °C or 1°C or 1 °F (selectable); Accuracy (ambient temp. 25°C): ±0,1 °C ±1 digit

CX series standard refrigeration temperature controller

Controller xr02cx-5n0c1 compressor, shutdown defrosting

Controller xr02cx-5r0c1 compressor, shutdown defrosting, blue nixie tube display

Controller xr03cx-5n0c1 compressor, alarm dual output, shutdown and defrosting

Controller xr04cx-5n0c1 compressor, defrosting dual output

Controller xr06cx-5n0c1 compressor, defroster and fan three outputs

Controller xr06cx-5r0c1 compressor, defroster, fan three outputs, blue display
