Dixell Agent Electronic Digital Display Built-in Real-time Clock Thermostat Xr75cx

Housing: self extinguishing ABS.
Case: frontal 32x74 mm; depth 60mm;
Mounting: panel mounting in a 71x29mm panel cut-out
Protection: IP20; Frontal protection: IP65
Connections: Screw terminal block  2,5 mm2 wiring.
Power supply: according to the model 24Vac, ±10%; 230Vac 10%, 50/60Hz, 110Vac 10%,
50/60Hz
Power absorption: 3VA max
Display: 3 digits, red LED, 14,2 mm high; Inputs: Up to 4 NTC or PT1000 probes.
Digital inputs: free voltage contact
Relay outputs: compressor SPST 8(3) A, 250Vac or SPST 16A 250Vac
defrost: SPDT 8(3) A, 250Vac
fan: SPST 5A, 250Vac
aux: SPDT 8(3) A, 250Vac or SPST 16(6)A 250Vac
Data storing: on the non-volatile memory (EEPROM).
Internal clock back-up: 24 hours
Kind of action: 1B; Pollution grade: 2;Software class: A.;
Rated impulsive voltage: 2500V; Overvoltage Category: II
Operating temperature: 0÷55°C; Storage temperature: -30÷85 °C.
Relative humidity: 2085% (no condensing)
Measuring and regulation range: NTC probe: -40÷110°C (-40÷230°F);
PT1000 probe: -100÷150°C (-148÷302°F)
Resolution: 0,1 °C or 1°C or 1 °F (selectable); Accuracy (ambient temp. 25°C): ±0,7 °C ±1 digit

Prime CX series refrigeration system thermostat

Controller xr10cx-5n1c1 compressor, no defrosting. With ttll to RS485 serial port, suitable for centralized monitoring

Controller xr20cx-5n1c1 compressor, shutdown and defrost. With ttll to RS485 serial port, suitable for centralized monitoring

Controller xr30cx-5n1c1 compressor, alarm dual output, shutdown and defrosting. With ttll to RS485 serial port, suitable for centralized monitoring

Controller xr40cx-5n1c1 compressor, defrosting dual output. With ttll to RS485 serial port, suitable for centralized monitoring

The controller xr60cx-5n1c1 has three outputs: compressor, defroster and fan. With ttll to RS485 serial port, suitable for centralized monitoring

The controller xr70cx-5n1c3 has four outputs: compressor, defroster, fan and alarm (Library lamp). With ttll to RS485 serial port, suitable for centralized monitoring

Controller xr70cx-5n0i3 compressor, defrosting (with clock), fan, alarm (Library lamp) four outputs. With ttll to RS485 serial port, suitable for centralized monitoring

Controller xr75cx-5n7c3 compressor, defroster, fan, multi-functional four output. With ttll to RS485 serial port, suitable for centralized monitoring

Controller xr75cx-5n6i3 compressor, defrosting (with clock), fan, multifunctional four output. With ttll to RS485 serial port, suitable for centralized monitoring

The controller xr570c-0n0c3 is an old model, and its function is similar to that of xr70cx

Controller xr35cx-5n7i3 compressor, alarm or warehouse light dual output, shutdown and defrosting. With RS485 serial port, it is suitable for centralized monitoring

Controller xr64cx-5n0c3 compressor, double fans and three outputs. With ttll to RS485 serial port, suitable for centralized monitoring

The controller xr72cx-5n0c3 has four outputs: compressor, defroster, fan and 2 compressor. With ttll to RS485 serial port, suitable for centralized monitoring

Controller xr77cx-5n7c3 compressor, defroster, fan, multi-function, four outputs, independent terminals. With RS485 serial port, it is suitable for centralized monitoring
