Mobile Sand Making Machine
US$ 5000 - 8000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Shisheng Machinery
Place of Origin:
China
Model Number:
PCL-600
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
30 days
Related Products
Brand Name
Shisheng Machinery
Place of Origin
China
Model Number
PCL-600
Certification
ISO, CE
After-sales Service Provided
Engineers available to service machinery overseas
Warranty
1 years
Weight
5.6t
Dimension(L*W*H)
2800*1500*2030mm
Production Capacity
12-30t/h
Condition
New
Voltage
380V 50HZ or Customized
Power(W)
2*30kw
High Efficiency Mobile Sand Making Machine Features:
The structure is simple, and the operating cost is low.
High efficiency, and low consumption.
It can be fine crush, crude grind material and it is easy to maintain.
It is slightly influenced by the humidity of material, and the max. humidity is 8%.
It is more suitable for crushing mid-hardness materials and high-hardness materials.
Its product is cubic, and the density of pilling up is high and the iron pollution is low.
The working noise is less than 75 decibels and dust pollution is light.
Mobile Sand Making Machine Technical Parameter:
| Model | Impeller Speed(r/min) | Max.Feed Size(mm) | Capacity(t/h) | Power(kw) | Weight(t) | Overall Dimension(mm) |
| PCL-600 | 2000-3000 | 30 | 12-30 | 2*30 | 5.6 | 2800*Φ1500*2030 |
| PCL-750 | 1500-2500 | 35 | 25-55 | 2*45 | 7.3 | 3300*Φ1800*2440 |
| PCL-900A | 1200-2000 | 40 | 55-100 | 2*55 | 12.1 | 3750*Φ2120*2660 |
| PCL-900B | 1000-1450 | 40 | 65-130 | 2*75 | 13.6 | 3750*Φ2300*2090 |
| PCL-1050 | 1000-1700 | 45 | 100-160 | 2*(90-110) | 16.9 | 4480*Φ2450*2906 |
| PCL-1250 | 850-1450 | 45 | 160-300 | 2*(132-180) | 22 | 4563*Φ2650*3716 |
| PCL-1350 | 800-1193 | 50 | 200-360 | 2*(180-220) | 26 | 5340*Φ2940*3650 |
| Model | HXVSI-7611 | HXVSI-8518 | HXVSI-9526 | HXVSI-1140 | HXVSI-1145 | HXVSI-1150 | |
| Handling Capacity(t/h) | Waterfall and Central Feed | 120-180 | 200-260 | 300-380 | 450-520 | 500-610 | 520-650 |
| Whole Center Feed | 60-90 | 100-130 | 150-190 | 225-260 | 245-355 | 255-365 | |
| Maximum Feed Size(mm) | Soft Material | 35 | 40 | 45 | 50 | 50 | 50 |
| Hard Material | 30 | 35 | 40 | 40 | 45 | 45 | |
| Speed(r/min) | 1700-1890 | 1520-1690 | 1360-1510 | 1180-1310 | 1150-1300 | 1150-1300 | |
| Double Motor Power(kw) | 4P 110kw | 4P 180kw | 4P 264kw | 4P 400kw | 4P 400kw | 4P 500kw | |
| Shape Size(L*W*H)(mm) | 3700*2150*2100 | 4140*2280*2425 | 4560*2447*2778 | 5100*2700*3300 | 5500*2700*3300 | 5500*2700*3300 | |
