Home > Electrical & Electronics > Power Transmission & Transformer > Transformer > Acrel 300286 Medical IT Isolated Power Supply Monitoring System ICU Insulation Monitor AIM-M100
Acrel 300286 Medical IT Isolated Power Supply Monitoring System ICU Insulation Monitor AIM-M100
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2003
Factory Size:
3,000-5,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hospital ICU/CCU Insulation Monitoring Device AIM-M100 IEC CertNegotiableMOQ: 1 -
Acrel Medical IT System Insulation Monitoring Device for Medical Location With Insulation SystemNegotiableMOQ: 1
-
Medical Insulation Monitoring Devices AIM-M100 Monitor the Insulation Resistance of IT SystemsNegotiableMOQ: 1
-
Acrel Isolated Power Monitor System for Hospital Isolated Power SystemNegotiableMOQ: 1
-
Acrel AID120 Medical Isolation Alarm and Display Device for Medical Isolated Power SystemNegotiableMOQ: 1
AIM-M series insulation monitor
Product Description
Characteristic
AIM-M Series insulation monitor is a high-performance insulation monitoring device,and is dedicated to medical IT systems. It is used to monitor the state of the ground insulation.When the system has an insulation fault,it can send out alarm signals in time.It helps staff to deal with the actual situation.The product is with extensive display and alarm indication function,user-friendly,and easy to operate.
Function
1. real time monitor and fault alarm of the ground insulation resistance,
2. transformer load current and transformer winding temperature of the monitored IT system,
3. be used with insulation fault locator, remotely starting fault-locating and displaying locating results when there are
insulation faults,
4. real-time monitor the line disconnection fault, temperature sensor disconnection fault and the functional grounding line disconnection fault of the monitored system, and give the alarm indication within 2S after the fault . occurs,
5. relay alarm output, LED alarm indication and other faults indication functions,
6. used for centralized alarm and display instrument, test signal generator, insulation fault locator and upper computer management software communications, and can monitor the operation status of IT system in real time.
7. Events logging function, which can record alarm occurrence time and fault type and is convenient for operation personnel to analyze the operation conditions of system and promptly eliminate the faults.
2. transformer load current and transformer winding temperature of the monitored IT system,
3. be used with insulation fault locator, remotely starting fault-locating and displaying locating results when there are
insulation faults,
4. real-time monitor the line disconnection fault, temperature sensor disconnection fault and the functional grounding line disconnection fault of the monitored system, and give the alarm indication within 2S after the fault . occurs,
5. relay alarm output, LED alarm indication and other faults indication functions,
6. used for centralized alarm and display instrument, test signal generator, insulation fault locator and upper computer management software communications, and can monitor the operation status of IT system in real time.
7. Events logging function, which can record alarm occurrence time and fault type and is convenient for operation personnel to analyze the operation conditions of system and promptly eliminate the faults.
Specification
Quotation
Model | Function | FOB Shanghai(USD) | Wholesale price | ||
AIM-M10 | Insulaton Monitoring;Auxiliary power supply AC220V | 1244 | Please contact us in detail. We can offer you the best price. | ||
AIM-M100 | Insulaton Monitoring;Auxiliary power supply AC220V | 1617 | |||
AIM-M200 | Insulaton Monitoring; Auxiliary power supply DC24V Supports the insulation fault location | 2032 | |||
Model Selection Description
AIM-M100 auxiliary power supply is AC220V,the product does not have insulation fault location.AIM-M200 auxiliary power is DC 24V.It has all the monitoring functions of AIM-M10 and AIM-M100 products,it also supports the insulation fault location.If you need insulation fault location,please choose AIM-M200.The positioning function can also be turned off through the menu.we supply full products of this cabinet from current transformers, meters to cabinets.
