AMC16 series multi-circuit monitoring device
1. General
AMC16 series multi-circuit monitoring device of Acrel Company is a measuring device designed specifically for the power supply management of server in the data center. Such device is small and exquisite in design, capable of centralized monitoring on various electric parameters and on-off states of dozens of circuits, including incoming line circuit and outgoing line circuit, and it achieves the highly integration of monitoring circuits in volume.
2.Technical Features
| Type | AMC16Z |
| Power distribution system | AC |
| Measuring parameters | Busbar voltage,current,active power,reactive power,power factor,active energy and reactive energy |
| Rated | 220V AC |
| Measurement range | 40~400V AC |
| Overload | instantaneous voltage twice |
| Input frequency | 45~60HZ |
| Auxiliary power supply | AC85~265V/DC100V~350V |
| Communication | 2-Wire Modbus-RTU |
3. Product specifications
| Model | The Basic Function | Optional Function |
| AMC16Z | Busbar voltage for measurement of three-phase total incoming lines+2-way three-phase incoming line current,active power,reactive power,power factor,active energy,reactive energy+36-way single-phase outgoing line current. |
1.2C-duplex communication 2.Dual-power supply may be required AC220V+DC48V |
FAQ:Thank you very much for your interest in Acrel E-Business (Shanghai) Co., Ltd.
, below are few questions you may ask answers.
1. Q: Does your factory have the design and development capabilities, can you factory accept customized products?
A: The staffs in our R&D department are well experienced in the Electric industry, with more than 10 years’ experience. We can make customized products especially for you; please kindly contact us for more
2. Q: How long could I get my order?
A: For stock Products: shipping within 5 days. For customized products: usually 10-15 days. It depends on your design and quantity.
3. Q: How is your production management and quality control system?
A: All our product process follows up ISO9001. The strict implementation of ISO9001 assures to provide error–free products to our customers. We will show you these in our workshop during your visiting.
4. Q: How can I get a sample to check the quality?
A: You can pay for you samples for test. Leave us message of the item you want and your city address. We will offer you detail sample packing information, and select the best way to deliver it.
