Acrel AMC16Z-FAK24 Multi channel data logger data center monitoring with RS485
- 1000 per Month
- T/T Credit Card
-
Acrel AMC16Z-FDK48 Multi-circuit Data center power distribution monitoring equipment for DC power system
-
Multi circuit power meter for data center monitoring AMC16MA multi circuit power meter
-
Acrel AC current sensor input:0-600A output:0-20mA/4~20mA diameter:50mm CTs accuracy class 0.2 0.5 current transducer BA50-AI/I
-
Acrel AC current sensor input:0-600A output:0-5V/0-10V diameter:50mm CTs accuracy class 0.2 0.5 current transducer BA50-AI/V
-
Acrel AC current transducer input:AC 0-10A output:DC 4-20mA/0-20mA CTs true RMS accuracy class 0.5 0.2 current sensor BA05-AI/I
-
Acrel AC current sensor input AC 0-10A output DC 4-20mA/0-20mA CTs true RMS accuracy class 0.5 0.2 current transducer BA05-AI/I
Product Description
AMC16Z-FAK24 Data Center Monitor Device
|
|
| Information | parameter | Company profile | Certificate |
Characteristic
* Rated U and I: AC 220/380V
* Multi-circuit: A+B independent 12 circuits(total 24) DC12V output
* RS485 Modbus-RTU
Function
* 12-road of each circuit of A+B independent 2 circuits the outgoing current, active power, active power, reactive power, 2-31 current harmonics,24DI
* 1 RS485 communication | |
| Installation: DIN 35mm Dimension(L*W*H): 180*94.3*75mm |
Wiring
Typical connection
| Information | parameter | Company profile | Certificate |
Parameter
| Information | parameter | Company profile | Certificate |
