30 Meter Monopole Painting Coating Wifi Tower
Monopole Tower
What Is Monopole Tower?
Monopole Tower belongs to the technical field of pipe towers, and includes a working platform connected with the tower body and the upper part of the tower body. The bottom wall of the tower body is provided with a lower door hole, and the wall of the work platform is provided with a door opening, and the antenna bracket is fixed on the fence of the working platform, and the structure of the tower body is set by the main pole of the ladder and the main pole of the ladder. A ladder formed by a crosspiece, the main pole of the ladder is fixedly connected with the support frame, and the support bracket is screwed with the connecting bracket disposed on the inner wall of the tower.
The advantages of the Monopole Tower are: the structure is simple and reasonable; the appearance is beautiful; the installation and use are convenient. And compared to the angle steel tower, the footprint is smaller.
Highlights of JIAYAO self-supporting tower
● Leading design concept.
● Versatility, modular design, flexible configuration of accessories.
● Tower group design, modification and adjustment.
● The tower section is universal, and the same tower section taken from the same mother tower is completely common in different tower types.
● Lower costs.
● Self-supporting tower light weight.
● Self-supporting tower installation cost is good.
● Self-supporting tower installation time is short.
● High reliability.
● The design and processing of JIAYAO's self-supporting tower products are in line with ISO 9001:2000 quality management system.
● 50 years design life.
What Is The Details of JIAYAO Monopole Tower?
Design standard |
TIA/EIA-222-G/F |
Welding standard |
AWS D1.1 |
Galvanization standard |
ASTM A123 |
Design Wind Speed |
Up to 200 km/h |
|
Angular steel Material quality |
Mild Steel:Q235B/ASTM A36/S235JR |
High Steel:Q345B/ASTM A572/S355JR | |
Allowable deflection |
0.5 ~1.0 degree |
Bolt grade |
Gr 4.8, Gr 6.8, Gr 8.8 |
Marking |
Hydraulic Press Stamping |
What is the height of JIAYAO Monopole Tower we can provide?
5m up to 80m is the tower height we can provide.
What antenna can be mounted on JIAYAO Monopole Tower?
Type of antenna |
Description |
Panel antenna (sector antenna) |
GSM antenna for 5G:2.52m×0.265m×0.13m, 1.31m×0.32m×0.11m |
Parabolic reflector(dish antenna) |
Microwave antenna Diameter:0.6m, 0.9, 1.2m, 1.6m, 1.8m, 2.4m |
RRU |
Radio Remote Unit:0.45m×0.32m×0.25m |
WIFI antenna |
Grid or parabolic directional antenna / yagi / omnidirectional antennas |
Other Antenna |
VHF/UHF Dual-band Antenna FM antenna |
