Wxsoon 3*D Tungsten Carbide Drill Bits for Hardened Steel

Wxsoon 3*D Tungsten Carbide Drill Bits for Hardened Steel thumbnail-1
Wxsoon 3*D Tungsten Carbide Drill Bits for Hardened Steel thumbnail-2
Wxsoon 3*D Tungsten Carbide Drill Bits for Hardened Steel thumbnail-3
Wxsoon 3*D Tungsten Carbide Drill Bits for Hardened Steel thumbnail-4
Wxsoon 3*D Tungsten Carbide Drill Bits for Hardened Steel thumbnail-5
Wxsoon 3*D Tungsten Carbide Drill Bits for Hardened Steel photo-1
Wxsoon 3*D Tungsten Carbide Drill Bits for Hardened Steel photo-2
Wxsoon 3*D Tungsten Carbide Drill Bits for Hardened Steel photo-3
Wxsoon 3*D Tungsten Carbide Drill Bits for Hardened Steel photo-4
Wxsoon 3*D Tungsten Carbide Drill Bits for Hardened Steel photo-5
US$ 5 - 15 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Brand Name:
WXSOON
Place of Origin:
China
Model Number:
WXSOON-3D
Contact Supplier Request Quote Chat Now
Wuxi Soon Technology Co.Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name WXSOON
Place of Origin China
Model Number WXSOON-3D
Material Tungsten Carbide
Type Twist Drill Bit
Use Metal Drilling

wxsoon 3*D tungsten carbide drill bits for hardened steel

Flute Diameter



mm

 Thread Dimension
Metric 		Shank Diameter



mm

 Total Length



mm

 Flute Length



mm

 Limit Depth



mm

 Shank Length



mm
3.00
6.00 62 20 14 36
3.25
6.00 62 20 14 36
3.30 M4 6.00 62 20 14 36
3.40
6.00 62 20 14 36
3.50
6.00 62 20 14 36
3.70
6.00 66 20 14 36
4.00
6.00 66 24 17 36
4.20 M5 6.00 66 24 17 36
4.30
6.00 66 24 17 36
4.50
6.00 66 24 17 36
4.65
6.00 66 24 17 36
4.80
6.00 66 28 20 36
5.00 M6 6.00 66 28 20 36
5.10
6.00 66 28 20 36
5.20
6.00 66 28 20 36
5.50
6.00 66 28 20 36
5.55
6.00 66 28 20 36
5.80
6.00 66 28 20 36
6.00
6.00 66 28 20 36
6.10
8.00 79 34 24 36
6.20
8.00 79 34 24 36
6.30
8.00 79 34 24 36
6.50
8.00 79 34 24 36
6.60
8.00 79 34 24 36
6.80 M8 8.00 79 34 24 36
6.90
8.00 79 34 24 36
7.00 M8X1 8.00 79 34 24 36
7.10
8.00 79 41 29 36
7.40
8.00 79 41 29 36
7.50
8.00 79 41 29 36
7.80
8.00 79 41 29 36
8.00
8.00 79 41 29 36
8.10
10.00 89 47 35 40
8.40
10.00 89 47 35 40
8.50 M10 10.00 89 47 35 40
8.60
10.00 89 47 35 40
8.70
10.00 89 47 35 40
8.80
10.00 89 47 35 40
9.00 M10X1 10.00 89 47 35 40
9.30
10.00 89 47 35 40
9.50
10.00 89 47 35 40
9.60
10.00 89 47 35 40
9.80
10.00 89 47 35 40
10.00
10.00 89 47 35 40
10.25 M12 12.00 102 55 40 45
10.40
12.00 102 55 40 45
10.50 M12X1.5 12.00 102 55 40 45
10.60
12.00 102 55 40 45
10.80
12.00 102 55 40 45
11.00
12.00 102 55 40 45
11.20
12.00 102 55 40 45
11.50
12.00 102 55 40 45
11.80
12.00 102 55 40 45
12.00 M14 12.00 102 55 40 45
12.25
14.00 107 60 43 45
12.50 M14X1.5 14.00 107 60 43 45
12.70
14.00 107 60 43 45
12.75
14.00 107 60 43 45
12.80
14.00 107 60 43 45
13.00
14.00 107 60 43 45
13.10
14.00 107 60 43 45
13.50
14.00 107 60 43 45
13.80
14.00 107 60 43 45
14.00 M16 14.00 107 60 43 45
14.25
16.00 115 65 45 48
14.50 M16X1.5 16.00 115 65 45 48
14.75
16.00 115 65 45 48
14.80
16.00 115 65 45 48
15.00
16.00 115 65 45 48
15.10
16.00 115 65 45 48
15.50
16.00 115 65 45 48
15.80
16.00 115 65 45 48
16.00
16.00 115 65 45 48
16.50
18.00 123 73 51 48
16.75
18.00 123 73 51 48
16.80
18.00 123 73 51 48
17.00
18.00 123 73 51 48
17.50
18.00 123 73 51 48
17.80
18.00 123 73 51 48
18.00
18.00 123 73 51 48
18.50
20.00 131 79 55 50
18.80
20.00 131 79 55 50
19.00
20.00 131 79 55 50
19.50
20.00 131 79 55 50
19.80
20.00 131 79 55 50
20.00
20.00 131 79 55 50


Product Tags: Tungsten carbide drill bits , drill bits for hardened steel , wxsoon 3*D drill bits
