Help CenterVertical Horizontal Lift Slide Pallet Mechanical Puzzle Parking System Multi Floors Multi Rows Fast Speed Low Noise Electricity Saving Car Parking Lift With CE for Sale Low Price
Related Products
-
Sell Auto-parking System (PSH2)US$ 2900/ - 2900/MOQ: 6 Pieces -
Parking SystemUS$ 25000 - 25000MOQ: 20 Pieces
-
Pit Lifting Parking SystemUS$ 20000 - 20000MOQ: 20 Pieces
-
High Levels High Speed Puzzle Parking SystemUS$ 45000 - 45000MOQ: 30 Pieces
-
Multi-parking, Tower Parking, Rotary Parking, China Parking Systems Manufacturer Supplier, China Parking FactoryUS$ 6800 - 6800MOQ: 30 Pieces
|
Work Principle This system is designed with 5 layers and multi-columns layout. Each layer is designed with a spare space as an exchanging space. All spaces can be auto-lifting freely except the spaces in the first layer and all the spaces can be auto-transverse moving except the spaces in the top layer. When a space needs to park or release a car, all spaces under the space will make a one space transverse moving to the empty space and forms a lifting channel under this space. In this case, the space will go up and down freely. When it reaches the ground, the car will go out and in freely.
Characteristics
Main Structure
Technical Parameters Mode of driveHydraulic Size of car (L×W×H)5000mm×1850mm×1550mmWeight of car2000kgLifting motor power11kw Lifting speed18-25m/min Sliding motor power0.2kwSliding speed7.5m/minElectricityAC380V,50Hz, 3 phases 5 wires systemSafeguard devicesHydraulic whole protection and anti-fall frameAnti-fall frame (our patent)Warning devicesSound, light, electricityMalfunction indicationFault diagnosis by computer, liquid crystal displayFrame compositionColumns and beams are made of H type steel, Channel steel, angle steel and square pipes;Parts appearance treatmentGalvanized treatment and high-grade anti-corrosion paintModes of operationLCD/ IC card/ManualControllerPLCWay of parking in and outForwarding, reversing into the space
|
|
|
|
|
|
