Pneumatic Handheld Drilling Rig ZQS Series

Pneumatic Handheld Drilling Rig ZQS Series photo-1
Pneumatic Handheld Drilling Rig ZQS Series photo-2
Pneumatic Handheld Drilling Rig ZQS Series photo-3
US$ 200 - 600 MOQ: 50 Sets
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2000
Factory Size:
3,000-5,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
tianjin port
Delivery Detail:
10 days
Scope of application
Ink lung ZQS - 50/2.5 S long pneumatic hand-held drill is a independent research and development of a new generation of drilling machine, applicable to the hardness of sf6, half coal rock in coal roadway side help anchor homework, homework with six kelly, twist drill pipe, drill bit and anchor rod (rope) mixer complete side help anchor operation, can also be used to drain, drainage, gas, coal, water injection, such as pressure relief hole drilling, hole operations.
Product features
Small volume, high speed, light weight, easy operation and high efficiency
Specification
Performance parameter
Unit
Parameter values
parameter values
parameter values
Work stress
MPa
0.40
0.50
0.63
Nominal torque
N·m
40
50
55
Rated speed
r/min
460
480
500
Maximum power output
kW
1.9
2.5
2.8
Maximum load torque
N·m
55
65
75
Power stall torque
N·m
65
80
90
Starting torque
N·m
60
70
80
Air consumption at load
m3/min
3.8
4.7
5.8
No-load speed
r/min
950
1050
1150
1/2 no-load speed
r/min
475
525
575
1/2 no-load torque
N·m
35
40
45
Sound pressure level Noise
dB(A)
110
Sound power level Noise
dB(A)
105
Heavy machine
Kg
11
Dimensions of drilling tail connection
mm
B19、B22、Twist drill
