hard guide way heavy duty auto flat bed torno parallel cnc lathe machine machinery with big spindle bore made in china
Product application:
The machine through the numerical control system,this machine could process different inner bore,ex-circle,circular conical surface and screw thread,especially suitable for the small and middle-sized shaft and plate work piece from rough processing in batch.It has advantages like higher automaticity,simpler programming and higher accuracy.
Product features:
Higher stability one-piece machine bed
3-gear spindle speed,step-less in gear
Higher rigidity pedestal
Wider layer board
Integrated automatic lubrication system
Product main technical specifications:
|
Specifications |
Unit |
CK6185E |
|
Max.swing over bed |
mm |
Φ850 |
|
Max.swing over cross slide |
mm |
Φ480 |
|
cessing length |
mm |
1000/1500/2000/3000 |
|
X/Z axis travel |
mm |
X:450 Z:1200/1700/2200 |
|
Spindle transmission type |
|
3 steps variable speed |
|
Spindle speed steep |
|
stepless |
|
Spindle speed |
rpm |
25-850 |
|
Spindle nose |
|
C11 |
|
Spindle bore |
mm |
Φ105 |
|
Spindle taper |
|
Metric 120-1:20 |
|
Spindle motor |
kW |
11 |
|
Ball screw dia.and pitch |
|
3205/5010(6310) |
|
X/Z axis feed motor torque |
N.m |
X:10 Z:15(22) |
|
X/Z axis rapid traverse |
m/min |
4/5 |
|
X/Z axis repeatability |
mm |
±0.005 |
|
Processing accuracy |
|
IT6-IT7 |
|
Workpiece surface roughness |
|
Ra1.6 |
|
Tailstock sleeve dia. |
mm |
Φ100 |
|
Tailstock sleeve travel |
mm |
250 |
|
Tailstock sleeve taper |
# |
MT6 |
|
Tool post type |
|
4 station electric tool post (optional:6 station turret) |
|
Cutting tool shape size |
mm |
32x32 |
|
Guide form |
|
Flat bed cnc lathe |
|
Total power capacity |
KVA |
15 |
|
Machine dimension(LxWxH) |
mm |
3300/3800/4300x2000x2000 |
|
Net weight |
kg |
3900/4500/5400 |
Details:
1:How can I choose the most suitable machines?
A: Please tell me your specifications (or send your workpiece drawing to us) ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Band Saw Machine ,Shaper machine and so on .
3: How long is the delivery time?
For standard machines,it would be around 30 days;For non-standard machines and customized machine according to client’s specifications requirements,it wouble be a little longer.
4.Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277599 China.
You are warmly welcomed to visit us.
5. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
6: What's the Payment Terms?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
