Home > Manufacturing & Processing Machinery > Machine Tools > CNC Machine Tools > Linear Rail Economical Small Bt30 XH7121 Cnc Mini Vertical Machining Center
Linear Rail Economical Small Bt30 XH7121 Cnc Mini Vertical Machining Center
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Port of Shipment:
Shenzhen
Main Markets:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Location:
Shenzhen, Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
XH7121 Small Size Mini VMC 3 Axis 4 Axis BT30 Linear Guide GSK Siemens Control CNC Vertical Machining CenterNegotiableMOQ: 1 -
Chinese VMC-650 VMC650 Atc Cnc Vmc Vertical Milling Machine Machining Center Price for SaleNegotiableMOQ: 1
-
Hi Precision Chinese VMC650 VMC 450 550 850 1060 Vertical Milling Machine Cnc Machining CentersNegotiableMOQ: 1
-
High Precision 3/4 Axis VMC850 Vertical Cnc Milling Machine Centre Machining Center PriceNegotiableMOQ: 1
-
3/4 Axis VMC850 Machining Center Cnc Vertical Milling MachineNegotiableMOQ: 1
linear rail economical small bt30 XH7121 cnc mini vertical machining center
Product Main Specifications:
Model |
XH7121 |
Table Size |
700×210mm |
T Slot (width × qty × spaces) |
12mm × 4 |
Max. Loading Weight On Worktable |
200kgs |
X/Y/Z Axis Travel |
365 × 260 × 440mm |
Distance From Spindle Nose To Table |
60-405mm |
Distance From Spindle Center To Column |
270mm |
Max. Spindle Speed |
6000-8000rpm |
Spindle Taper |
BT30 |
ATC capacity |
8pcs |
Max. Loading Weight of tools |
3.5kgs |
Positioning Accuracy |
±0.02mm |
Repeatability Accuracy |
±0.01mm |
Main Motor Power |
2.2/3.7KW--- 14/23.7 NM (servo motor) |
Rapid feeding speed (X,Y,Z Axis) |
12-15 m/min |
Feeding speed |
0-4000m/min |
Machine weight |
1300kgs |
Details:
FAQ:
1:How can I choose the most suitable machines?
A: Please tell me your specifications (or send your workpiece drawing to us) ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Band Saw Machine ,Shaper machine and so on .
3: How long is the delivery time?
For standard machines,it would be around 30 days;For non-standard machines and customized machine according to client’s specifications requirements,it wouble be a little longer.
4.Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277599 China.
You are warmly welcomed to visit us.
5. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
6: What's the Payment Terms?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
7: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
A: Please tell me your specifications (or send your workpiece drawing to us) ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Band Saw Machine ,Shaper machine and so on .
3: How long is the delivery time?
For standard machines,it would be around 30 days;For non-standard machines and customized machine according to client’s specifications requirements,it wouble be a little longer.
4.Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277599 China.
You are warmly welcomed to visit us.
5. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
6: What's the Payment Terms?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
7: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
