3/4 Axis VMC 650 VMC650 Cnc Vertical Milling Machine Centre Machining Center
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Port of Shipment:
Shenzhen
Main Markets:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Location:
Shenzhen, Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Low Cost VMC650 VMC Cnc Vertical Machining Center Machine Price for SaleNegotiableMOQ: 1 -
CE Standard High Rigidity 3/4 Axis VMC650 Cnc Vertical Milling Machine Centre VMC Machining Center PriceNegotiableMOQ: 1
-
China Automation Control GSK Siemens FANUC Control 3 Axis VMC650 Cnc Metal Vertical Machining Center PriceNegotiableMOQ: 1
-
High Speed China 4 Axes GSK Siemens FANUC Control VMC650 Taiwan Vertical Cnc Machining Center 3 Axis for Metal PriceNegotiableMOQ: 1
-
New Economy 3 Axis 4 Axes GSK Siemens FANUC Control VMC650 Taiwan Cnc Vertical Machining Center Price for SaleNegotiableMOQ: 1
3/4 axis VMC 650 VMC650 cnc vertical milling machine centre machining center
Product characteristics:
VMC650 is a new generation vertical machining center. It can be used in aerospace, military industry, hydropower, wind
power,automobile parts, machining, precision machining and mould manufacturing. Small parts and non-ferrous metals high-speed and high-precision automatic processing. Integral casting FEM finite element analysis, dynamic simulation completely eliminate structural stress, to ensure the best rigidity and stability.
Widely used in mechanical processing, mold, instruments, instruments and other industries. The main components, such as base,fuselage, worktable, middle slide, lift slide and so on, are cast with high strength material, and the stability of machine tool is ensured by artificial aging.
power,automobile parts, machining, precision machining and mould manufacturing. Small parts and non-ferrous metals high-speed and high-precision automatic processing. Integral casting FEM finite element analysis, dynamic simulation completely eliminate structural stress, to ensure the best rigidity and stability.
Widely used in mechanical processing, mold, instruments, instruments and other industries. The main components, such as base,fuselage, worktable, middle slide, lift slide and so on, are cast with high strength material, and the stability of machine tool is ensured by artificial aging.
Product Main Specifications:
Specification |
Unit |
VMC550 |
VMC650 |
VMC850 |
VMC1060 |
Table size |
mm |
800×260 |
800×400 |
1000×500 |
1300×600 |
T-slot (NO.x width x pitch) |
mm |
3-16 |
3-16-120 |
5-18-100 |
5-18-120 |
Max.table load |
kg |
300 |
400 |
500 |
600 |
Guide rail type |
Linear rail guide |
Linear rail guide |
Linear rail guide |
Linear rail guide |
|
X/Y/Z axis travel |
mm |
500×300×400 |
650×400×500 |
800×500×500 |
1000×600×500 |
Distance from spindle nose to worktable |
mm |
90-490 |
70-570 |
100-600 |
70-670 |
Distance from spindle center to column |
mm |
360 |
450 |
580 |
655 |
Spindle taper |
BT40 |
BT40 |
BT40 |
BT40 |
|
Spindle Speed |
rpm |
8000 |
8000 |
8000 |
8000 |
Spindle Drive |
Belt |
Belt |
Belt |
Belt |
|
Spindle Motor |
kw |
3.7 |
5.5 |
7.5 |
11 |
X/Y/Z axis rapid feed speed |
m/min |
20/20/20 |
24/24/20 |
24/24/24 |
20/20/16 |
X/Y/Z axis cutting feed rate |
mm/min |
1-6000 |
1-10000 |
1-10000 |
1-10000 |
Tool changer |
Hat type-12T |
16T |
Arm type-24T |
Arm type -24T |
|
Positioning accuracy |
mm |
±0.01/300 |
±0.01/300 |
±0.008/300 |
±0.01/300 |
Repeat Positioning accuracy |
mm |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
Machine dimensions(L*W*H) |
mm |
2100×1700×2200 |
2300×2000×2350 |
2200×2350×2550 |
3000×2500×2800 |
Machine weight(N.W/G.W) |
T |
2.0 |
3.0 |
5.0 |
5.8 |
Details:
Optional accessories(need add extra cost):
The 4th axis;
Chip-conveyor.
Arm type tool changer.
Tool setter.
FAQ:
1:How can I choose the most suitable machines?
A: Please tell me your specifications (or send your workpiece drawing to us) ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Band Saw Machine ,Shaper machine and so on .
3: How long is the delivery time?
For standard machines,it would be around 30 days;For non-standard machines and customized machine according to client’s specifications requirements,it wouble be a little longer.
4.Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277599 China.
You are warmly welcomed to visit us.
5. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
6: What's the Payment Terms?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
7: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
A: Please tell me your specifications (or send your workpiece drawing to us) ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Band Saw Machine ,Shaper machine and so on .
3: How long is the delivery time?
For standard machines,it would be around 30 days;For non-standard machines and customized machine according to client’s specifications requirements,it wouble be a little longer.
4.Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277599 China.
You are warmly welcomed to visit us.
5. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
6: What's the Payment Terms?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
7: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
