Structure
Universal testing machine adopts mechatronics design, mainly composed of load cell, transmitter, microprocessor, load driving mechanism, computer and color inkjet printer. It has a wide and accurate loading speed and force measurement range, has high accuracy and sensitivity for the measurement and control of loads and displacements, and can also perform constant-speed loading and constant-speed displacement automatic control experiments.
Technical index of foam universal testing machine
| Maximum load | 2000KG |
| Accuracy class | 0.5 grade |
| Effective force measurement range | 0.4% to 100% (0.5 level) |
| Force measurement accuracy | Within ± 0.5% of displayed value |
| Effective test width | 400mm (can be widened) |
| Effective stretching space | 800mm (can be customized) |
| Test speed range | 0.1 ~ 500mm / min |
| Displacement measurement accuracy | Within ± 0.5% of displayed value |
| Test bench safety device | Electronic limit protection |
| Test bench lifting device | Fast / slow speed automatic control, jog |
| Overload protection | 10% over the maximum load, the machine automatically protects |
| Fixture configuration | Set of stretching jigs |
| Host size | 1200 * 530 * 1800mm (length * width * height) |
| power system | Servo motor high precision ball screw |
| power supply | 220V / 50HZ, |
| power | 0. 75KW (optional) |
| Host weight | (Approx.) 300 Kg |
Test force measurement:
Load measurement: The high-precision spoke-type load sensor is used, coupled with a high-performance measurement and amplification system, to ensure the high resolution of the test force. Multiple sensors can be configured according to user needs to achieve a wide range of test force measurement.
Displacement measurement: Use 2500P / R high-precision photoelectric encoder to rotate coaxially with precision lead screw, and realize the measurement power control system through digital circuit
Adopt full digital servo controller, control high-performance stepper motor to drive synchronous toothed belt, drive two pairs of high-precision and clearance-free precision lead screw transmission, with stable loading, good low-speed performance, no clearance, high transmission efficiency, low noise Features of smooth transmission.
Deformation measurement system:
Large deformation measurement system can be selected according to the requirements of test standards
