Double Column Tensile Strength Measurement Test Device For Plastic
- 1000 per Month
- T/T Credit Card
You May Like
-
analog display zwick roell plastic analyzer universal test machine with lvdt
-
used Hongjin universal testing machine self calibration 10kn price
-
Double column zwick steel rebar bolt utm universal tensile testing machine
-
50kn 100kn Touch Screen Tensile Strength Tester Textile Tension and Tearing Testing Machine
-
100kn Electronic Force Testing Machine For Scaffolding Fastener Strength Test
-
200KN 300KN Universal Force Machine for Tension Compression Bend Test
Product Description
Structure
Universal testing machine adopts mechatronics design, mainly composed of load cell, transmitter, microprocessor, load driving mechanism, computer and color inkjet printer. It has a wide and accurate loading speed and force measurement range, has high accuracy and sensitivity for the measurement and control of loads and displacements, and can also perform constant-speed loading and constant-speed displacement automatic control experiments.
Technical index
| Maximum load | 2000KG |
| Accuracy class | 0.5 grade |
| Effective force measurement range | 0.4% to 100% (0.5 level) |
| Force measurement accuracy | Within ± 0.5% of displayed value |
| Effective test width | 400mm (can be widened) |
| Effective stretching space | 800mm (can be customized) |
| Test speed range | 0.1 ~ 500mm / min |
| Displacement measurement accuracy | Within ± 0.5% of displayed value |
| Test bench safety device | Electronic limit protection |
| Test bench lifting device | Fast / slow speed automatic control, jog |
| Overload protection | 10% over the maximum load, the machine automatically protects |
| Fixture configuration | Set of stretching jigs |
| Host size | 1200 * 530 * 1800mm (length * width * height) |
| power system | Servo motor high precision ball screw |
| power supply | 220V / 50HZ, |
| power | 0. 75KW (optional) |
| Host weight | (Approx.) 300 Kg |
Test force measurement:
Load measurement: The high-precision spoke-type load sensor is used, coupled with a high-performance measurement and amplification system, to ensure the high resolution of the test force. Multiple sensors can be configured according to user needs to achieve a wide range of test force measurement.
Displacement measurement: Use 2500P / R high-precision photoelectric encoder to rotate coaxially with precision lead screw, and realize the measurement power control system through digital circuit
Adopt full digital servo controller, control high-performance stepper motor to drive synchronous toothed belt, drive two pairs of high-precision and clearance-free precision lead screw transmission, with stable loading, good low-speed performance, no clearance, high transmission efficiency, low noise Features of smooth transmission.
Deformation measurement system:
Large deformation measurement system can be selected according to the requirements of test standards
1. Are your company a trading one or a factory?
Factory ,13years focusing on test instruments field,3 years exporting experience.Our factory is in Dongguan, Guangdong, China
2. Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,
we offer 12 months for the FREE maintenance, while considering of sea transportation,
If your machine doesn't work, you can send E-mail to us and we will try our best to find
the problem by email or skype video chat if neccesary. After confirmation of the problem,
we can send you new spare parts or provide on-site repair.
3. What's the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery
time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider
making a special arrangement for you.
4. Do you accept customization service? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines, but also customized
machines according to your requirements. And we can also put your logo on the machine.
5. Do you have a branch company or service office in my country?
We have offices in the belowing:
Hangzhou Branch:
Address: Building 1, Haixiang Industrial Park, No. 1413 Moqianshan Road, Xiangfu Town, Gongshu District, Hangzhou, Zhejiang, China
6. How to install and use the product?
We will send you operating instructions, English video by Email. Or you can download on our
officail website directly.
Most of our machine is shipped with a whole part, which means it is already installed, all you
need to do is to connect the power cable and start to use. And if possible, we can also install
your machine at site.
7. What about the services and product' quality?
Service: ,Design service,Buyer lable service.
Quality: Each instruments must be carried out 100% quality examination and test, the finished products must through a third party
calibration institutions before shipping and delivery goods.
