Product Overview

XY-AI-500 Automatic JRT Roll Paper Cutting Machine

Outline
The equipment is the latest research and development which is the extension of the company with the current market situation. Using PLC program control, big screen true color human-computer interface. The precise servo control feed length, electro-mechanical integration control and other international advanced technology con automatically detect each key action, has good fault information prompt system, make the whole production line achieving the best working state.

Video Link: https://youtu.be/Xx0Xflc4ZT8
Function & Features
1.The main motor using the inverter independent drive.
2.For one set of machine, the cutting diameter of paper roll is adjustable as 100~280mm.
3.The equipment adopts automatic sharpening system, grinding wheel can be automatic feeding adjustment according to the blade loss.
4.The grinding system is equipped with an independent dust removal device to ensure the working environment.
5.The band saw adopts hydraulic tension system to ensure the tension of band saw.
6.It will be automatic stop and alarm when the knife is broken.
7.High precision servo system is used to ensure the quality of finished products. 8.According to the raw materials and the length of finished products, the number of finished products can be calculated automatically.
9.The device stops working and prompts the interface when the input data is wrong.
10.Using band saw for cutting and reduces the cost of use of users.
11.The thickness of finished paper core should less 3mm(Suggestion).
Details Images
Finished Products
Product Paramenters
Cutting speed
15-30cuts/minute
Cutting blade size
5180*100*1.05mm
Log length
≦2200mm or ≦2850mm
Tolerance
±2mm
Cutting length
≦300mm
Cutting diameter
150-300mm(Adjustable)
Thickness of paper core
≦3 mm
Power supply
15KW 380V 50HZ 3phases
Machine weight
2700KG
Overall size of machine
5300*2350*2200mm
Related Products

XY-TQ-B Automatic Maxi Roll Paper Making Machine
