Protective cover / enclosed metal sheet fiber laser cutting machine 1530 1000W 1500W 2000W metal plates fiber laser cutter
Technology Parameter
|
Machine Name |
Metal plate fiber laser cutting machine LXFC3015 |
|
Model |
LXFC3015 |
|
Laser machine cutting area |
1500x3000mm(Other size can be customized,such as 4500x1500/6000x1500/6000x2000mm) |
|
Fiber Laser Power |
500w/750w/1000/1500/2200/3300/4000/6000/8000/12000/25000W |
|
Laser wave length |
1064nm |
|
Transmission system |
Gear + rails (we have standard brand,we can also produce as your requirements) |
|
X.Y axis location accuracy |
±0.01mm |
|
X.Y axis repeat location accuracy |
±0.01mm |
|
X.Y axis max moving speed |
30m/min |
|
Max cutting speed |
1--30m/min(it will according to metal material and laser power) |
|
Cutting thickness |
Detailed in the following cutting thickness |
|
Application Material |
Metal sheet Iron/CS/SS/Aluminum/Copper and all kinds metal |
|
Gross weight |
4000KG |
|
Net weight |
3800KG |
|
Machine size |
4800*2600*1860mm |
Applied materials and Industry:
Application Materials:
Mainly used for cutting carbon steel, silicon steel, stainless steel, aluminum alloy, titanium alloy, galvanized steel sheet, pickling board, aluminum zinc plate, copper and many kinds of metal materials cutting and so on.
Application Industries: Applied in sheet metal processing, aviation, spaceflight, electronics, electrical appliances, subway parts, automobile, machinery, precision components, ships, metallurgical equipment, elevator, household appliances, gifts and crafts, tool processing, adornment, advertising, metal foreign processing various manufacturing processing industries.
Contact us to check more information NOW!
(1). Excellent beam quality: Smaller focus diameter and high work efficiency, high quality.
(2). High cutting speed: Cutting speed is more than 20m/min.
(3). Stable running: Adopting the top world import fiber lasers, stable performance, key parts can reach 100,000 hours.
(4). High efficiency for photoelectric conversion: Compare with CO2 laser cutting machine, fiber laser cutting machine has three times photoelectric conversion efficiency.
(5). Low cost & Low maintenance: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine. Fiber line transmission no need reflect lens, save maintenance cost.
(6). Easy operations: fiber line transmission, no adjustment of optical path.
(7). Super flexible optical effects: Compact design, easy to flexible manufacturing requirements.
(8). Adopted Original Raycus or German IPG fiber laser source: with long using life up to 150000 hours and high cutting speed up to 15m/min.
(9). Japan YASKAWA Servo motor with gear driving system: can make sure the cutting high precision especially comparing with the single driver system.
(10). Imported World Famous "LaserMech" laser head with auto focusing height follower (Optional): which can ensure the constant same distance between the head and cutting material. (11). The cutting slot is very slim, can reach up to 0.05mm: The machine is very suitable for processing precision parts with high efficiency.
(12). Automatic Lubrication System for Mechanic: which can lubricate the linear guiderail nearly 500 times per minute to make sure the high precision.
(13). Convenient Collecting System: which has the special funnel design to make collecting more easy.
We can also customized non-standard assist equipment as your detailed work requirements.
Feedback from around the world :
Contact us to check more information NOW!
FAQ
Q1 :How about warranty?
A1: 3 years quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge(some parts will be maintained) when if any problem during the warranty period.
Q2:2 I don’t know which one is suitable for me ?
A2:Please tell me
1). Your materials.
2). Max size of your material.
3). Max cut thickness.
4). Popular cut thickness.
Q3:Payment terms?
A3: Alibaba trade assurance/TT/West Union/Payple/LC/Cash and so on.
Q4:Do you have CE document and other documents for customs clearance?
A4: Yes,we have Original. At first we will show you and And after shipment we will give you CE/Packing list/Commercial Invoice/Sales contract for customs clearance.
Q5:I don’t know how to use after i receive Or i have problem during use,how to
do?
A5:
1). We have detailed user manual with pictures and CD,you can learn step by step.And our user manual update every month for your easy learning if there is any update on machine.
2). If have any problem during use,you need our technician to judge The problem elsewhere will be solved by us. We can provide team viewer
/Whatsapp/Email/Phone/Skype with cam till all of your problems finished.We can also provide Door service if you need.
