Refinery Ladle Furnace With Electrode Lifting Mechanism

FOB Price

Negotiable

1 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Refinery ladle furnace with Electrode lifting mechanism

Adoption of new technology:

1.Tubular water cooled furnace lid

2.Electrode lifting mechanism ( single phase, three phase)

3. Optimize large current system structure (energy-saving type)

4.PLC controller of electrode automatic lifting regulator

5.Automatic control argon blowing system

6.Frequency control ladle car

7. Industrial automatic control

8.Network technique

Parameters of Refinery ladle furnace(hot sale)with Electrode lifting mechanism

ladle	ladle	Transformer	Electrode Diameter	Electrode distribution circle	Molten steel	Vacuum pump	Vacuum tank size	limit	ladle
Rated Capacity	Diameter	Rated Capacity		Diameter	Temperature raising speed	Air exhaust capacity		vacuum degree	Weight
(t)	(mm)	(kVA)	(mm)	(mm)	°C/min	(kg/h)	(mm)	(pa)	(t)
20	2200	3150	200	500	2-3	150	3800/4100	67	23
40	2900	6300	350	650	2-3	250	4800/5000	67	30
60	3100	10000	350	650	2-3.5	360	5300/5500	67	35
70	3200	12500	400	700	2-3.5	380	5400/5600	67	43
100	3400	18000	400	700	2-3.5	400	5500/5800	67	47
150	3900	20000	450	800	2-3.5	450	6300/6600	67	52
