Small capacity electric induction melting furnace
Small capacity electric induction melting furnace
Application:
Small electric melting furnace for copper scarp are mainly used for the melting of steel, stainless steel, copper, brass, silver, gold ,glass and aluminium materials, etc. Melting capacity can be from 3KG to 500KG.
Feature:
1. Easy to install and operate. No need make foundation or any civil work.
2. Super small size and portable, occupies not enough 1.0 square meters.
3. 24 hours no-stop melting ability.
4. Energy saving and environmental protection.
5. It's easy to change furnace to melt different materials.
6. Using crucible: No need skilled person for making lining by refractory material as the normal by induction furnace
7. With digital display of working frequency, current, voltage, power
Technical Parameters:
1.Melting ability
Model |
Maximum input power |
Melting ability of common materials |
||
Steel and stainless steel |
Brass, copper, silver, gold |
Aluminium |
||
IGBT-15 |
15KW |
3KG |
10KG |
3KG |
IGBT-25 |
25KW |
5KG |
20KG |
5KG |
IGBT-35 |
35KW |
10KG |
30KG |
10KG |
IGBT-45 |
45KW |
18KG |
50KG |
18KG |
IGBT-70 |
70KW |
25KG |
100KG |
25KG |
IGBT-90 |
90KW |
40KG |
120KG |
40KG |
IGBT-110 |
110KW |
50KG |
150KG |
50KG |
IGBT-160 |
160KW |
100KG |
250KG |
100KG |
Manual Tilting Small Induction melting 3kg-100kg Furnace
2. Installation Drawing
Packaging & Shipping
♦ Package: One piece in one plywood case
♦ Shipping: By Sea
Small capacity electric induction melting furnace
1. Inquiry response within 24 hours.
2. Ensure every quotation is practical &customized according to your requirement.
3. Provide the design suggestions and layout plan for the client’s workshop.
4. Provide the technical specification of the auxiliary facilities.
5. Provide professional proposal for the whole project.
6. Engineers are available to serve the machines overseas.
7. Our factory always welcome to your visit. We can take you to visit our local customers.
8. Quality assurance: 18months except consumable parts.
