Product Description

Bundor One Way Check Valve 8 Inch Non-Return Valve HT200



Product Advantages :

1. Double-plate and efficient operation of the valve seat design, light weight.

    2.The clip sealing surface, the use of small size and light weight design, can install different standard flanges


3.The seal uses a variety of different elastomers mixed lining or alloy to meet different application needs.



4.Open and close the valve plate, the average distribution of the load on each valve plate, so that the valve plate can quickly react.



5.Long leg spring, so that the valve plate quickly closed, reducing the friction on the valve body.Bundor One Way Check Valve 8 Inch Non-Return Valve HT200

Name 1-Body 2-Stem 3-Spring 4-Disc 5-Ring
Material DI 304 SS304 DI PTFE
DN NPS L±1.5 D D1 D2
50 2'' 43 101 58 65
65 2  1/2'' 46 118 75 80
80 3'' 64 132 85 94
100 4'' 64 157 105 117
125 5'' 70 186 125 145
150 6'' 76 213 165 170
200 8'' 89 272 215 224
250 10'' 114 328 260 265
300 12'' 114 378 300 310
