Help CenterBundor DIN Flange 5 Inch Ductile Iron Flange Gate Valve With Prices
Related Products
-
Bundor F5 Flange Sluice Gate Valve DN50-DN600 PN16 Double Bonnet 4 Inch Water Gate ValveNegotiableMOQ: 1 -
Bundor 4" WCB Price Class 150 Flanged Rising Stem Gate Valve With PricesNegotiableMOQ: 1
-
Bundor 8 Inch CF8 Manual Operated Rising Stem SS Stainless Steel 316 Flange Gate ValveNegotiableMOQ: 1
-
Bundor DIN F4 4 Inch Gate Valve Manufacture Supplier With Prices Brass Sluice ValveNegotiableMOQ: 1
-
Bundor HT200 DN80 Double Flanged Connection Outside Stem PN16 Soft Seal 5k Gate ValveNegotiableMOQ: 1
Product Features:
1.Budor product quality is covered by China Pacific Insurance with two million dollors. Bundor Valve, Two Years Warranty, Pay Two Back If One Bad. Any quality problems of the product itself, we will pay without conditions.
2.The body is ductile iron,high level than national stanard.Tensile strength is 450Mpa,elongation is large than 10%,can not be broken easily when transport.
3. Both inner and out part is epoxy coating, the thickness is 250μm minimum,can prevent rust well,can be used in sewage system.
4.The wedge is coated with EPDM, the EPDM proportion can reach 50%,steable and good resilient.
5.O rings are used on 2Cr13 stem,can reduce friction,prevent leakage,can change sealing ring with stop water.
| Name | 1-Body | 2-Seat | 3-Disc | 4-Stem | 5-Actuator |
| Material | DI | EPDM | DI | 2Cr13 | Manual |
| DN | NPS | L | ΦA | ΦB | ΦC |
| 50 | 2" | 150 | 165 | 125 | 102 |
| 65 | 2 1/2" | 170 | 185 | 145 | 122 |
| 80 | 3" | 180 | 200 | 160 | 138 |
| 100 | 4" | 190 | 220 | 180 | 158 |
| 125 | 5" | 200 | 250 | 210 | 188 |
| 150 | 6" | 210 | 285 | 240 | 212 |
| 200 | 8" | 230 | 340 | 295 | 268 |
| 250 | 10" | 250 | 405 | 355 | 320 |
| 300 | 12" | 270 | 460 | 410 | 378 |
| 350 | 14" | 290 | 520 | 470 | 438 |
| 400 | 16" | 310 | 580 | 525 | 490 |
| 450 | 18" | 330 | 640 | 585 | 550 |
| 500 | 20" | 350 | 715 | 650 | 610 |
| 600 | 24" | 390 | 840 | 770 | 725 |
| 700 | 28" | 430 | 910 | 840 | 795 |
| 800 | 32" | 470 | 1025 | 950 | 900 |
| 900 | 36" | 510 | 1125 | 1050 | 1000 |
| 1000 | 40" | 550 | 1255 | 1170 | 1115 |
| 1200 | 48" | 630 | 1485 | 1390 | 1330 |
Certifications
Our Services
FAQ
Q:When the products will be shipped ?
A:Within 7-15 days after receing the prepayment.
Q:Do you have OEM service ?
A:Yes . A variety of products size , quality and quantity can be cutomized according to your needs.
Q:Could you offer a free sample ?
A:Yes , samples can be proveded for free.
Q:How can I pay for the products ?
A: We accept a variety of payment methods. Such as T/T , L/C,D/P ,Western Union , Paypal ,Trade Assurance.
Q: How do you deal with that if there are some quality problems in products?
A: We will be responsible for all the quality problems.
Q:Are you a facrory or trade company ?
A: We are a factory with 24 years experience in valve research and production .
