5 Core H07RN -F VDE Rubber Power Cable
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
2001
Annual Export Value:
US$1.5 Million - US$2.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HOT SALE: H07RNF Rubber Insulated Rubber Sheathed Power Cable 450/750VNegotiableMOQ: 1 -
ASTM Standard Power Cable H07RN-F and Rubber CableNegotiableMOQ: 1
-
Hot !!! H07RN-F Rubber Copper CableNegotiableMOQ: 1
-
Hot Selling Soft Sheathed Rubber Cable H07rn-fNegotiableMOQ: 1
-
Chinese Rubber Double Insulated Cable for South AmericaNegotiableMOQ: 1
Tough Rubber Sheathed Cable
RUBBER SHEATHED CABLE
H05RR-F/H05RN-F/H07RN-F VDE certificate
Heavy machine cable, hoist cable or tower crane cable or lift cable
UL,VDE,CCC,CE ,ISO19001,ISO14001 certification
ROSH REACH STANDARD
| rubber cable & welding cable-China-YC YCW | ||||||
| Explain: | ||||||
| Reference Standard: JB8735-98,GB5013-97 | Rated Voltage:450/750V | Rated Temperature:not exceed 65°C | ||||
| Conductor:Copper/tinned copper | Insulation: Rubber Compound | Sheath: Rubber Compound | ||||
| 1.Characteristics: have a certain extent of temperature resistance and oil resistance, fit to work outside and work in the smeary environment. | ||||||
| Application: Applied in electrical appliance, electromotive tools,all kind of movable electric equipments and implemental cable, can support biggish mechanical outside force. | ||||||
| Normal Cross Sectional Area of Conductor(mm2 ) | Normal Diameter of Strand(mm) | Normal Thickness of Insulation(mm) | Normal Thickness of Jacket(mm) | Over Diameter of Cable(mm) | Max Conductor Resistance at 20°C(≤Ω/km) | |
| 1×1.5 | 0.25 | 0.8 | 1.4 | 5.8~6.7 | 13.3 | |
| 1×2.5 | 0.25 | 0.9 | 1.4 | 6.5~7.2 | 7.98 | |
| 1×4 | 0.3 | 1 | 1.5 | 7.6~8.5 | 4.95 | |
| 1×6 | 0.3 | 1 | 1.6 | 8.5~9.5 | 3.3 | |
| 2×1 | 0.2 | 0.8 | 1.3 | 8.2~9.1 | 19.5 | |
| 2×1.5 | 0.25 | 0.8 | 1.5 | 9.1~10.1 | 13.3 | |
| 2×2.5 | 0.25 | 0.9 | 1.7 | 10.9~12.4 | 7.98 | |
| 2×4 | 0.3 | 1 | 1.8 | 12.9~14.8 | 4.95 | |
| 2×6 | 0.3 | 1 | 2 | 14.7~16.6 | 3.3 | |
| 3×1 | 0.2 | 0.8 | 1.4 | 8.9~9.9 | 19.5 | |
| 3×1.5 | 0.25 | 0.8 | 1.6 | 9.8~11.1 | 13.3 | |
| 3×2.5 | 0.25 | 0.9 | 1.8 | 11.7~13.4 | 7.98 | |
| 3×4 | 0.3 | 1 | 1.9 | 13.8~15.7 | 4.95 | |
| 3×6 | 0.3 | 1 | 2.1 | 15.7~17.6 | 3.3 | |
| 4×1 | 0.2 | 0.8 | 1.5 | 9.8~11.1 | 19.5 | |
| 4×1.5 | 0.25 | 0.8 | 1.7 | 10.8~12.3 | 13.3 | |
| 4×2.5 | 0.25 | 0.9 | 1.9 | 12.9~14.8 | 7.98 | |
| 4×4 | 0.3 | 1 | 2 | 15.3~17.2 | 4.95 | |
| 4×6 | 0.3 | 1 | 2.3 | 17.5~19.7 | 3.3 | |
| 5×1 | 0.2 | 0.8 | 1.6 | 10.8~12.3 | 19.5 | |
| 5×1.5 | 0.25 | 0.8 | 1.8 | 11.9~13.8 | 13.3 | |
| 5×2.5 | 0.25 | 0.9 | 2 | 14.2~16.1 | 7.98 | |
| 5×4 | 0.3 | 1 | 2.2 | 17.0~19.1 | 4.95 | |
| 5×6 | 0.3 | 1 | 2.5 | 19.5~21.6 | 3.3 | |
